Specifications
Brand Name :
WINCOO
Model Number :
YT-C series
Certification :
CE
Place of Origin :
CHINA
MOQ :
1 set
Price :
USD 800-2500 1set
Payment Terms :
L/C, D/A, D/P, T/T
Supply Ability :
100 set/month
Delivery Time :
30 days
Packaging Details :
Export package
Description
YT-C Series Two-Stage Hydraulic Tank Lifting Jack: Precision Engineering for Large-Scale Storage Tank Construction
What is a Hydraulic Tank Lifting Jack?

A hydraulic tank lifting jack is a specialized heavy-duty lifting system designed for the vertical construction (downward or upward) of large storage tanks. Unlike standard automotive jacks, this system utilizes synchronized hydraulic cylinders, a centralized PLC control unit, and a modular configuration to lift tons of steel evenly. It is the core equipment for the inverted (jack-up) construction method, allowing workers to assemble the tank from the top ring down, minimizing the need for high-altitude work and heavy cranes.

YT-C Series Two-Stage Hydraulic Tank Lifting Jack: Precision Engineering for Large-Scale Storage Tank Construction
Key Technical Parameters (YT-C Series)

The YT-C series is engineered to handle various tank sizes, from small field-erected vessels to massive 100,000 m³ storage tanks. Below are the standard specifications:

Model Max Service Pressure Single Cylinder Output Max Stroke Lifting Speed Motor Power
YT10-2200C 24 Mpa 10 Tons 1250 mm 190 mm/min 5.5 kw
YT18-3000C 25 Mpa 18 Tons 1600 mm 187 mm/min 5.5 kw
YT25-2700C 31.5 Mpa 25 Tons 1650 mm 175 mm/min 5.5 kw
YT30-2700C 29 Mpa 30 Tons 2050 mm 130 mm/min 4.0 kw

Note: Custom configurations are available. The system supports module configurations where the number of cylinders can be adjusted based on tank circumference and total weight.

Why Choose Our Hydraulic Jack?
  • Superior Synchronization & Safety: The system utilizes PLC central control to manage lifting precision. Each cylinder is equipped with a safety valve that automatically locks the load in place, even in the event of a power outage or hydraulic hose rupture, preventing sudden drops.
  • High Efficiency: The modular design allows for rapid installation. Each lifting cycle (one full stroke) takes approximately 15 minutes, significantly speeding up the welding schedule for annular plates.
  • Simplified Hydraulics: We utilize a single high-pressure hose per cylinder. This design minimizes the risk of oil leakage commonly associated with traditional multi-hose configurations.
  • Two-Stage & Long Stroke: The YT-C series features a two-stage cylinder design, providing a long stroke capable of lifting a full ring course in one go, eliminating the need for frequent re-shimming.
Where is it Used?

This equipment is specifically designed for vertical storage tank construction.

  • Applications: Crude oil reserves, chemical storage tanks, LNG/LPG tanks (including C-type fuel tanks for vessels), and water treatment tanks.
  • Construction Method: Ideal for the Inverted (Jacking) Installation Method, where the roof is lifted, and subsequent shell courses are welded at ground level, reducing safety risks and crane costs.
