Specifications
Model NO. :
SP116
Pressure :
Pressurized
Interior Material :
Stainless Steel
Collector Components :
Glass Vacuum Tube
Composition :
Collector
Certification :
CE, ISO9001, CCC, Solar Keymark
Solar Water Heater Capacity :
100L 150L 200L 250L 300L 400L 500L
Solar Water Heater Accessories :
Solar Collector, Upright Water Tank, Work Station
Fuction :
Control and Circulation
Type :
Micro computer
Transport Package :
Carton
Specification :
50L to 500L
Trademark :
QIRUI/OEM
Origin :
China
HS Code :
841919100
Production Capacity :
4000sets Per Month
MOQ :
1 Piece
Price :
US $800 / Piece
Description
Split Pressure Solar Water Heater Work Station SP116 with CE
Split Pressure Solar Water Heater Pump Work Station Sp116 with CESplit Pressure Solar Water Heater Pump Work Station Sp116 with CESplit Pressure Solar Water Heater Pump Work Station Sp116 with CESplit Pressure Solar Water Heater Pump Work Station Sp116 with CE
System demonstration

Main technical details

01. Dimension: 380× 220× 140mm
02. Input voltage: 200V-240V AC or 100V-120V AC
03. Power: ≤ 3W
04. Accuracy of temperature measuring: ± 1centigrade
05. Range of temperature measuring: PT1000: 0-199centigrade NTC10K: 0-99centigrade
06. Input signals:
1*PT1000 sensor temperature probe ≤ 500centigrade, silicon cable ≤ 280centigrade;
2*NTC10K sensor temperature probe≤ 135centigrade, PVC cable ≤ 105centigrade
07. Output signals:
1*Auxiliary heating output (Max. Load current: 10A)
2*Relay output (Max. Load current: 3A)
08. System design pressure: 1 MPa
System working pressure: 0.8 MPa
09. Safety valve respond pressure: 0.6 MPa
10. pump model: SR15/6
11. Screw coupling: 1/2"
12. Pipeline Material: Yellow copper
13. Secondary display screen device (For choice)
14. LCD-display
15. Range of environment temperature: -10-50centigrade
16. Water protection grade: IP40

Main Functions

01. Time display
02. Temperature difference circulation
03. Storage tank overheating protection
04. Emergent stop of system overheating
05. Frost protection of pipeline and collector
06. Three periods of time adjustable on pipeline circulation
07. Three periods of time adjustable on auxiliary heating
08. Holiday function*
09. Anti-bacteria function*
10. Three speed levels on circulation pump
11. Display flow rate
12. Display system pressure
Packing list
No. Item Specification Quantity
1 Work station 385×220×135mm 1 pc
2 PT1000 sensor 15m 1 pc
3 NTC sensor 3m 3 pcs
4 Main Power cable 1 pc
5 Auxiliary heater cable 1 pc
6 P2 output cable 1 pc
7 Filling valve 1 pc
8 Fixed screw 1 bag
9 Manual 1 pc
