63MM Stainless Steel Glass Clamp AISI304 316 D Shape Glass Holder Plate
63MM Stainless Steel Glass Clamp AISI304 316 D Shape Glass Holder Plate
63MM Stainless Steel Glass Clamp AISI304 316 D Shape Glass Holder Plate
63MM Stainless Steel Glass Clamp AISI304 316 D Shape Glass Holder Plate
Specifications
MOQ :
100 pcs
Size (mm) :
63 × 45 × 26 (overall dimensions)
Payment Terms :
L/C,D/P,D/A,T/T,Western Union
Tube Compatibility (Φ) :
FLAT / 33.7 / 42.4 / 48.3 (as per model)
Model Number :
QH500
Model No. :
QH500.00 / .33 / .42 / .48
Rubber Gasket :
QHR series (as per glass thickness)
Glass Thickness :
8mm / 8.76mm / 10mm / 10.76mm / 12mm
Certification :
CE certifiate/ ISO9001
Material :
Stainless Steel AISI304 (interior) / 316 (exterior)
Place of Origin :
Qingdao, China
Surface Finish :
Satin / Mirror (optional)
Brand Name :
Railing-O
Product Type :
Middle D-Shape Glass Holder with Plate / Glass Clamp
Description
D-Shape Glass Holder 63×45×26mm with Plate for 8-12mm Panels AISI304/316 Satin/Mirror QH500
Product Overview

The QH500 series middle D‑shaped clamps with plate are mid‑sized, precision‑engineered accessories designed for securing glass panels to various tube profiles in frameless railing systems. Manufactured from high‑quality stainless steel – AISI316 for exterior and marine applications, with AISI304 option for interior use – these 63×45×26mm clamps feature an integrated mounting plate for enhanced stability and simplified installation. The series offers versatile mounting options with flat surfaces or round tubes of 33.7mm, 42.4mm, and 48.3mm diameter. Each clamp is paired with a dedicated rubber gasket (QHR500 series) to accommodate glass thicknesses from 8mm to 12mm, providing a secure, vibration‑free hold while protecting glass edges. Available in satin or mirror finish, the QH500 series delivers reliable performance and discreet aesthetics for residential and commercial glazing installations.

Key Highlights
  • High-quality manufacturing standards
  • Robust design for long-term reliability
  • Optimized for professional B2B applications
  • Integrated mounting plate – provides enhanced stability and simplifies attachment to surfaces or tubes.
  • Mid‑sized robust design – 63×45×26mm dimensions deliver enhanced strength for larger glass panels.
  • Versatile mounting options – flat and round tube configurations (33.7, 42.4, 48.3mm) for flexible railing system design.
  • Glass compatibility – accommodates 8mm to 12mm panels with dedicated QHR500 series rubber gaskets for each thickness.
  • Rubber gasket protection – QHR500 series gaskets provide vibration damping and glass edge protection.
  • Material versatility – AISI316 for exterior/coastal applications; AISI304 for interior use.
  • Two finish options – satin brushed or mirror polished for design flexibility.
  • Corrosion‑resistant – stainless steel construction ensures long‑term durability.
  • ISO9001 certified – quality assurance with MTC documentation available.
Applications

Ideal for glass panel mounting in frameless balustrades, shower screens, glass partitions, and display systems – including balconies, terraces, staircases, hotels, shopping centres, and office buildings. The mid‑sized design is particularly suited for installations requiring enhanced strength and stability for thicker glass panels.

Technical Specifications
Parameter Value
Product Type Middle D‑Shaped Glass Clamp with Plate
Series QH500
Material AISI316 (standard / exterior) / AISI304 (optional / interior)
Surface Finish Satin or Mirror (optional)
Clamp Dimensions 63 × 45 × 26 mm
Mounting Type Surface‑mounted / Tube‑mounted
Installation Location Indoor & Outdoor
Certification MTC, ISO9001
Model Tube / Surface Rubber Gasket Glass Thickness
QH500.00 Flat QHR50008 8 mm
QH500.33 33.7 mm QHR50876 8.76 mm
QH500.42 42.4 mm QHR50010 10 mm
QH500.48 48.3 mm QHR51076 10.76 mm
— — QHR50012 12 mm
Packaging & Delivery

Each clamp is individually wrapped with its corresponding rubber gasket in protective packaging, packed in cartons, and loaded onto pallets for secure transit. Custom packaging available on request. Delivery timelines are arranged according to order quantities and production schedules; we guarantee on‑time shipment as committed. MTC and ISO9001 certification documents accompany every consignment.

Why Choose Us
  • Integrated plate design – enhanced stability and simplified installation.
  • Mid‑sized strength – 63×45×26mm design for enhanced support of larger glass panels.
  • Versatile mounting – flat and round tube options for flexible railing design.
  • Dedicated rubber gaskets – QHR500 series for each glass thickness, ensuring secure hold and edge protection.
  • Material choice – 316 for coastal durability, 304 for interiors.
  • Finish options – satin or mirror to match design schemes.
  • Quality certified – ISO9001 and MTC documentation included.
  • Factory‑direct value – competitive pricing with volume discounts.
