Stainless Steel Carbon Steel Drawer Type Activated Carbon Environmental Protection Adsorption Box
Stainless Steel Carbon Steel Drawer Type Activated Carbon Environmental Protection Adsorption Box
Stainless Steel Carbon Steel Drawer Type Activated Carbon Environmental Protection Adsorption Box
Stainless Steel Carbon Steel Drawer Type Activated Carbon Environmental Protection Adsorption Box
Stainless Steel Carbon Steel Drawer Type Activated Carbon Environmental Protection Adsorption Box
Stainless Steel Carbon Steel Drawer Type Activated Carbon Environmental Protection Adsorption Box
Specifications
Brand Name :
Qiaoda
Certification :
ISO
Place of Origin :
China
MOQ :
1 pc
Price :
negotiated price
Payment Terms :
D/A, D/P, T/T, Western Union
Supply Ability :
50 unit/month
Delivery Time :
5~10 day
Packaging Details :
wooden package
Application :
Industrial Waste Gas Treatment
Power Supply :
220V/380V
Efficiency :
≥99%
Noise Level :
≤75 dB
Control System :
PLC
Material :
Stainless Steel/Carbon Stell
Capacity :
customized
Description
Stainless Steel Carbon Steel Drawer Type Activated Carbon Environmental Protection Adsorption Box
High Quality Stainless Steel Carbon Steel Drawer Type Activated Carbon Environmental Protection Adsorption Box

The activated carbon exhaust gas treatment tank is a reliable equipment for air purification and exhaust gas treatment, widely used in industrial, commercial, and specialized environments including chemical plants, pharmaceutical facilities, and paint spray booths. Its primary function is to purify air by adsorbing harmful gases, odors, and volatile organic compounds (VOCs) to ensure compliance with environmental standards.

Key Features
Structural Composition
  • Shell: Constructed from durable metal materials (stainless steel or carbon steel) for corrosion resistance and structural integrity
  • Activated carbon filling layer: The core treatment component, available in granular, lump, or fiber form with loading method directly impacting adsorption efficiency
  • Air inlet and exhaust: System design ensures contaminated air enters through the inlet, passes through activated carbon layer, and exits as purified air
  • Fans: Optional fan systems enhance airflow and improve treatment efficiency when required
Applications
  • Chemical industry: Treatment of toxic gases from solvent evaporation and chemical reactions
  • Paint spraying industry: Removal of harmful paint components and solvent gases
  • Pharmaceutical industry: Elimination of odors and harmful gases generated during production
  • Food processing: Odor removal and air quality maintenance
  • Indoor air purification: Air quality improvement in offices, homes, and commercial spaces
Stainless Steel Carbon Steel Drawer Type Activated Carbon Environmental Protection Adsorption Box Stainless Steel Carbon Steel Drawer Type Activated Carbon Environmental Protection Adsorption Box Stainless Steel Carbon Steel Drawer Type Activated Carbon Environmental Protection Adsorption Box
Technical Specifications
Air Volume (m³/h) Thickness (mm) Number of Drawers Activated Carbon Quantity Dimensions (mm) Inlet/Outlet Size (mm)
5000 0.6 2 80 1050×1000×1320 400
10000 0.6 4 160 1700×1000×1320 500
15000 0.8 6 240 1700×1000×1320 500
15000 0.8 6 240 2100×1000×1320 500
20000 1.0 9 360 2100×1000×1320 600
20000 1.0 8 320 2700×1000×1320 600
25000 1.2 10 400 2900×1000×1320 600
30000 1.2 12 480 3000×1000×1320 800
40000 1.5 12 672 3000×1400×1320 800
50000 1.5 16 896 3000×1400×1500 800
Frequently Asked Questions
Do you provide after-sales service?
Yes, we provide engineer support for after-sales service.
How long is your warranty?
One year after delivery. We ship replacement parts free of charge for non-artificial damage during this period.
Which payment methods do you accept?
We accept telegraphic transfer, L/C, PayPal, cash, D/P, D/A, Western Union, and MoneyGram.
What kind of transportation do you offer?
Customers may choose air, land, or sea transportation options.
