Specifications
Place of Origin :
Guangdong, China (Mainland)
Brand Name :
HAIDA
Certification :
ISO 9001:2000; ISO 9001:2008; QS-9000; ISO 14001:2004; CE, , SMC, CMC, CPA, CE,CMA,IMC
Model Number :
HD-A535
Power :
Electronic
Port :
ShenZhen
MOQ :
1 Set
Price :
Negotiable
Packaging Details :
ach set protected with resin fiber and PP film, then put into Strong wooden case with operation man
Delivery Time :
20 days after order confirmed
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram,In cash, escrow
Supply Ability :
300 Sets per Month Haida
Product Name :
packaging clamping testing instruments
Design Criteria :
ASTM D6055
control :
PLC control
Specimen shape :
Parallelepiped transport package
Maximum specimen weight :
500kg
Description

PLC Control Package Testing Equipment , ASTM D6055 Packaging Clamping Testing Instruments

Introduction


The ISTA Package Clamping Force Testing Machine is simulated the impact strength of packaging in the real circumstance of transportation, for example, the transportation of goods. This product is applied to the scientific research institutions, colleges, packaging technique test centers, packaging material manufacturers and foreign trade or transportation departments.

Technical Parameters of ISTA Package Clamping Force Testing Machine:

Items Specification
Design standard ASTM D642, ASTM D6055, American SEARS enterprise standard
Sample shape parallelepiped transport package;
Maximum test weight 500KG
Clamping pressure 400-3000Lb (adjustable) pressure can be applied on the corresponding surface according to the transportation diagram on the test sample;
Plywood size H48in * D48in
Clamping plate height adjustment 0-1000mm
Lifting speed 50-300mm / min, set fixed speed
Spreading plate width 200-2000mm
Dimensions 2000 * 2800 * 2350mm
Sensor accuracy 1/100000
Measurement accuracy 1%
Clamping displacement accuracy ± 0.5MM
Power controller The computer displays the maximum power value in Chinese and English
Splint requirements Two gripping plates are 2000lb parallel and flat without deformation under working conditions, the vertical state between the splint and the floor, the thickness of the splint is ≥15mm, the splint can realize the action and cycle of clamping, opening, rising, and lowering cycle
Automatic stop mode set the upper and lower limits to stop
Transmission mode servo motor controls clamping force, and AC motor controls rise and fall
Protection device leakage protection, travel limit device
Can be connected to a computer
Working voltage AC 220V / 50HZ

​
