No-Rotor Rheometer Rubber Testing Machine ,Electronic Rotorless Rheometer Rubber Testing
No-Rotor Rheometer Rubber Testing Machine ,Electronic Rotorless Rheometer Rubber Testing
No-Rotor Rheometer Rubber Testing Machine ,Electronic Rotorless Rheometer Rubber Testing
No-Rotor Rheometer Rubber Testing Machine ,Electronic Rotorless Rheometer Rubber Testing
Specifications
Place of Origin :
Guangdong, China (Mainland)
Brand Name :
HAIDA
Certification :
ISO 9001:2000; ISO 9001:2008; QS-9000; ISO 14001:2004; CE, , SMC, CMC, CPA, CE,CMA,IMC
Model Number :
HD-R816
Power :
Electronic
Port :
ShenZhen
MOQ :
1 Set
Price :
Negotiable
Packaging Details :
Each set protected with resin fiber and PP film, then put into Strong wooden case with operation man
Delivery Time :
20 days after order confirmed
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram,In cash, escrow
Supply Ability :
300 Sets per Month Haida
Product :
rubber testing equipment
Temperature range :
Room temperature-200 degree
Temperature accuracy :
≤±0.3℃
Temperature resolutio :
0.1℃
Measuring range :
10 to 200 Mooney
Description

No-Rotor Rheometer Rubber Testing Machine ,Electronic Rotorless Rheometer Rubber Testing

Brief introduction

No-Rotor Rheometer is used for rubber quality control and it is widely used in rubber industry. It can offer accurate data for rubber optimization formula combination, such as the burning time, positive curing time, sulfide index and maximum and minimum torque.

The main technical parameters

Item Specification
Temperature Range Room temperature to 200°C
Temperature Resolution 0.01℃
Rate of temperature increase 15℃/min
Torque Range 0-25N.M
Torque Resolution 0.001N.M
Swing Angle ±0.5°,±1°,±2°,±3°(optional)
Swing speed 100r/min(1.66HZ)

No-Rotor Rheometer Rubber Testing Machine ,Electronic Rotorless Rheometer Rubber Testing

No-Rotor Rheometer Rubber Testing Machine ,Electronic Rotorless Rheometer Rubber Testing

Rubber

Ø ASTM D412, ISO 37-2005, JIS K6251, DIN 53504-2009: Tensile Strength & Elongation Test

Ø ASTM D1149-07, ASTM D1171-99, ISO 7326, ISO1431-1, DIN 53509-1: Ozone Aging Test

Ø ASTM D624-00, ISO 34-1: Tearing strength Test

Ø ASTM D395-03, ISO 815-1: Compression Set Test

Ø ASTM D2240-05, ISO 7619-1, JIS K6253, ISO 868: Shore Hardness Type A/D

Ø ASTM D573, ASTM D865, ISO188 Method B, DIN 53508 High/ Low Temperature Test

Ø ISO 2781(Method A): Density Test

Ø ASTM D5289-95/ ISO6502: No-Rotor Rheometer/CuremeterØ ASTM D1646: Mooney Viscometer
