Specifications
Model NO. :
GR-150
Grade :
Industrial Grade
Forming Way :
Extruded Graphite
Crystal Morphology :
Flake Graphite
Composition :
100% Carbon
Transport Package :
by Ply-Wood
Specification :
20-75mm
Trademark :
DC
Origin :
Beijing, China
HS Code :
2701121000
Supply Ability :
150PCS Per Day
Customization :
Available
Density :
1.6
Type :
Graphite Rod
Place of Origin :
China
Delivery Time :
Peak Season Lead Time: 6-12 months, Off Season Lead Time: 1-3 months
Payment Terms :
LC, T/T, D/P, PayPal, Western Union, Small-amount payment, Money Gram
MOQ :
1 Piece
Description
China manufacturer low density graphite anode rod:
Graphite rods are often used for following:
1. Refractory material:
Widely used in the metallurgical industry.
2. Conducting material:
In the electronics industry, widely used for graphite electrode, brush,, etc
3. Wear-resisting material and lubricant:
Use graphite as wear-resisting and lubrication materials, can be 100m/s speed sliding in - 200 ~ 2000 °C temperature range, no or less lubricanting oil.
4. Sealing material:
It can be as sealing ring in the equipment, such as centrifugal pump, hydraulic turbine , etc.
5. Anticorrosion material:
Widely used in petroleum, chemical, hydrometallurgy departments.
6. Protection materials
Insulation, high temperature resistant, radiation
Specifications:
Diameter length (mm) around weight kgs
Φ20 1700 1
Φ25 1700 1.5
1900 1.68
2200 1.95
2250 1.98
Φ30 1700 2
1900 2.24
2200 2.59
Φ35w 1700 2.85
1900 3.2
2100 3.52
2200 3.68
Φ40 1700 3.5
1900 4
2100 4.32
2200 4.63
2400 5.05
2270 4.7
Φ45 2250 5.21
Φ50 1700 5.5
1920 6.3
2100 6.8
2200 7.12
2500 8
Φ60 1400 6.5
1700 7.9
1300 6.04
Φ63 2000 8.7
Φ70 2100 5.68
2250 5.5
2500 6.3
Φ72 2250 15.7
2470 17
Φ75 2250 16.4
Technical date sheet:
Specifications Unit Value
Bulk Density g/cm3 1.65-1.80
Compressive Strength * MPa 20-55
Bending Strength * MPa 10-30
Elastic Modulus * GPa 9-21
Specific Resistance * μ Ω·m 5.0-15.0
Ash % 0.05-0.5
