Specifications
Brand Name :
Hochiry
Model Number :
GF20X
Certification :
TUV
Place of Origin :
CHINA
MOQ :
100Pcs
Price :
3.5USD/PCS
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
50000 Pieces per Week
Delivery Time :
3-5 days
Packaging Details :
Standard carton(500sets/ctn), 21g/set N.W:10.8KG G.W:11.3KG Size: 40*26*31cm
Product Name :
PV Solar Junction Box
Power :
300W
Rated Voltage :
1000V DC
Waterproof protection :
IP67
Rated Currrent :
25A
Flame Class :
UL944-V0
Safety Class :
Class I I
Description
IP67 BIPV Junction Box for Building Integrated Photovoltaic 4rails3diods 4mm2 Cable connectors Solar Panel Junction Box
Main View
Solar Panel Junction Box Is Used For Solar PV Panel Connection, It has Diode, Cable, Junction Box Body, Connector. This J-Box Is 1 Diode, Suitable For 50W-100W Solar Module
Features:
1. Certification, TUV, CE, RoHS
2. 25 Years Warranty
3. Back Body Stick To Panel Directly, Very Convenient To Install
4. Already Fit With Solar Connector and Wires Connection
Technical specifications:
Model Number
GF20X
Certification Number
TUV: R50348429
Rated Voltage
TUV 1500V ,UL 1000V, CSA 1500V DC
Temperature Range
-40C to +85C
Safety Class
Class II
Protection Degree
IP67
Wire Size Range
4mm2, 12AWG, 1Meter
Flame Resistance
V-0, 5VA
Waterproof Range
Potting Sealant
Volume Of Silicon Gel
24 ml
Width Of Copper Ribbons
Up to 8mm for soldering
Connection Method
Soldering
Insulation Material
PPE+PS/PA
Contact Material
Copper Alloy
Overall Size
10x8x16cm
Installation Steps
Box adhesive back plate
It's a very simple affixing operation between junction box and back sheet of PVmodule.

Making junction box facing down and injecting glue around the bottom
of the junction box
Solder ribbons of PV module passed
through sealing area.The box body is aligned in the right place of the back sheet.
Bus welding
Do not move the slotted
screwdriver, contacting the ribbon of PV-module with soldering iron tip,
remove the soldering iron until the tin layer melted, and remove the forceps
after tin curing.
Box filling
After the connection and assembly of the junction box and components, the inside part of the junction box must be injected with glue. The copper, diode and metal components inside of the junction box must be sealed with glue.
Install box lid
The box lids are placed above the junction box.
Press box lid down, The box lid in the right place when you hear "flap" sound obviously.
Notes

1, Keeping the box body a horizontal state when cover the lid.
2, Do not tilt the junction box when complete.
3, Required when installing the lid place panels across in the air currents 10 hours till the silicon cures.
