PE Pipe Fitting Making Machine Injection Molding Machine

APPLICATION:

The PE Pipe Fitting Making Machine is a high-precision injection molding machine specially designed for manufacturing polyethylene (PE) pipe fittings, such as elbows, tees, reducers, couplings, and valves. It ensures high production efficiency, consistent quality, and durability of fittings used in plumbing, irrigation, gas distribution, and industrial piping systems.

PE PIPE PRODUCTION SPECIFICATIONS:

PE Pipe Extrusion Line Process Flow

SINGLE-SCREW EXTRUDER---DIE HEAD & MOULD---VACUUM WATER COOLING TANK---WATER COOLING TANK---TRACTION---CUTTING MACHINE---AUTOMATIC UNLOADING RACK---SINGLE POSITION WINDER

Material Preparation

PE resin pellets are dried (if necessary) and fed into the hopper of the injection molding machine.

Pipe Sizing & Calibration

Vacuum Sizing Tank: The hot pipe enters a vacuum tank to solidify its outer diameter (OD) and ensure dimensional accuracy.

Pulling & Haul-Off

Haul-Off Unit: Motorized caterpillar tracks pull the pipe at a controlled speed, synchronizing with extrusion output.

Cutting & Stacking

Cutting Saw: An automatic cutter slices the pipe to specified lengths (e.g., 6m, 12m).

Quality Control

Wall Thickness Monitoring: Ultrasonic/laser sensors verify uniformity.

Key Advantages of PE Pipe Extrusion Line

High-speed injection for mass production

Energy-efficient hydraulic/PID temperature control

Durable mold design for long service life

Low maintenance & easy operation

PRE- AND AFTER-SALE SERVICES

• A great wealth of experience,

• A consistent focus on the highest quality

• A complete twin pipe vacuum sizing system;

• Controlled independently unitary structure twin pipe hauling mechanism and synchronous cutting device;

• Optional length set and accurate adaption stacker.

• A highly motivated team

• Sophisticated process technology

• Customized solutions
