Specifications
Pipe Size :
20-63mm; 3 layer
Model Number :
LB-60/38
Delivery Time :
45 WORKING DAYS
Control system :
PLC with remote control system
Payment Terms :
L/C,T/T,
Production Name :
PPR Glassfiber PPR Pipe Production Machine
Brand Name :
LB
Extruder Capacity :
350kgs/h for inner &outer +180kgs/h middle GF
Die head :
3 layer co-extrusion with two extruders
Place of Origin :
ZHANGJIAGANG
Supply Ability :
15 SETS PER MONTH
Packaging Details :
NORMAL PACKAGE
MOQ :
1 SET
Production speed :
12m/min; 20m/min; 28m/min
Certification :
CE / ISO
Description
16 to 1600mm Plastic PVC PPR PE HDPE Water Supply Drainage Irrigation Gas Pipe Making Machine Extrusion Line
3 Layer PPR Glassfiber Pipe Manufacturing Equipment
Advanced 20-63mm PPR pipe production line designed for manufacturing high-quality 3-layer PPR glassfiber pipes with exceptional precision and efficiency.
Technical Specifications
Line Model Screw Diameter L/D Ratio Production Scope Extruder Output Nominal Power Dimensions (L×W×H)
KDGF-65 ф65/50mm 33:1 ф20-63mm 150kgs/h 91KW 24×2.5×3
KDGF-60 ф60/65mm 36/33:1 ф20-110mm 340kgs/h 157KW 36×2.5×3
KDGF-75 Ф75/60mm 36:1 ф20-110mm 550kgs/h 248KW 45×2.5×3
Key Features & Advantages
High-efficiency PPR and Glassfiber extruders specifically designed for glassfiber characteristics, featuring superior wear and corrosion resistance for stable extrusion performance
Patented adjustable co-extrusion die head enables rapid, uniform multi-layer composition and optimal layer thickness control without extruder speed adjustments
Advanced combined cutting system ensures rapid, dust-free cutting across various pipe diameters during high-speed production
Self-developed control technology guarantees precise cutting accuracy and eliminates synchronization issues, uneven pipe lengths, and printing misalignment
Upgradeable configuration for producing high-speed three-layer or single-layer HDPE pipes through machine renovation
