Specifications
Application :
pipe making
Screw design :
Single-screw
Control :
PLC+Touch Screen
Gearbox :
Deling
Brand Name :
LB
Model Number :
LB
Certification :
CE,ISO
Place of Origin :
ZHANGJIAGANG
MOQ :
1 SET
Price :
negotiation
Payment Terms :
L/C,T/T
Supply Ability :
15 SETS PER MONTH
Delivery Time :
45 WORKING DAYS
Packaging Details :
NORMAL PACKAGE
Inverter :
ABB
Package :
Exported film packing
Voltage :
380V 50HZ
After-sales service provided :
Engineers available to service machinery overseas,Online support,Video technical support,Field installation,commissioning and training
Color :
Customised
Name :
PE Pipe Extrusion Line
Warranty :
1 Year
Motor :
Beide
Raw materia :
PE
Automatic grade :
Fully automatic
Description
Fully Automatic PE Corrugated Pipe Equipment ABB Inverter 380V 50HZ
Product Overview

Fully Automatic PE Corrugated Pipe Equipment with ABB Inverter, operating at 380V 50HZ, designed for high-efficiency production of single and double wall corrugated pipes.

Pipe Applications
  • Cable protection systems
  • Waste water management
  • Glass fiber conduits
  • Electrical installations
  • Control and computer cable routing
  • Automotive, machinery and aerospace applications
  • Medical equipment
  • Washing machines
  • Dishwashers
Key Features
High Performance Materials

PE Double Wall Corrugated Pipes offer excellent temperature resistance, corrosion and abrasion resistance, high intensity, and superior flexibility.

Advanced Perforating System

The corrugated pipe perforating machine features reasonable design, high automation, online/offline operation capability, producing smooth holes without residue.

Technical Specifications

HDPE/PP double wall corrugated pipe production line incorporating foreign advanced technology with multiple patented innovations.

Model Screw Diameter L/D Ratio Production Speed Machine Total Power Machine Size
SJ65/33 65mm 33:1 15m/min 55kw 27x1.5x3
SJ60/38 60mm 38:1 35m/min 90kw 34x1.5x3
SJ75/38 75mm 38:1 55m/min 160kw 58x2.5x3
Competitive Advantages
Technical Experience

Many years of expertise in extrusion equipment design and manufacturing, with core technology aligned with advanced European plastics processing standards.

Global Market Presence

Products sold throughout China and exported worldwide including Russia, Europe, Australia, Middle East, Asia, Americas, and Africa.

Comprehensive After-Sales Service

Turnkey project solutions with technician support for installation, commissioning, worker training, and 24-hour maintenance response.

Product Gallery
Fully Automatic PE Corrugated Pipe Equipment with ABB Inverter 380V 50HZ for High Efficiency Pipe Making Fully Automatic PE Corrugated Pipe Equipment with ABB Inverter 380V 50HZ for High Efficiency Pipe Making Fully Automatic PE Corrugated Pipe Equipment with ABB Inverter 380V 50HZ for High Efficiency Pipe Making Fully Automatic PE Corrugated Pipe Equipment with ABB Inverter 380V 50HZ for High Efficiency Pipe Making Fully Automatic PE Corrugated Pipe Equipment with ABB Inverter 380V 50HZ for High Efficiency Pipe Making Fully Automatic PE Corrugated Pipe Equipment with ABB Inverter 380V 50HZ for High Efficiency Pipe Making Fully Automatic PE Corrugated Pipe Equipment with ABB Inverter 380V 50HZ for High Efficiency Pipe Making
