Rotex Replacement Grommet Screen with 0.0014-0.0090 Inch Wire Diameter and 46%-76.4% Open Area for Mining Separation
Rotex Replacement Grommet Screen with 0.0014-0.0090 Inch Wire Diameter and 46%-76.4% Open Area for Mining Separation
Rotex Replacement Grommet Screen with 0.0014-0.0090 Inch Wire Diameter and 46%-76.4% Open Area for Mining Separation
Rotex Replacement Grommet Screen with 0.0014-0.0090 Inch Wire Diameter and 46%-76.4% Open Area for Mining Separation
Specifications
Brand Name :
CHINA HUATAO
Model Number :
HT
Certification :
ISO9001,CE,SGS etc.
Place of Origin :
China
MOQ :
1PCS
Price :
USD 100-200 per pcs
Payment Terms :
L/C,T/T,Western Union,Paypal
Supply Ability :
100PCS/MONTH
Delivery Time :
5-8 work days
Packaging Details :
Wooden Box or Carton Box
Product Name :
Rotex Compatible Grommet Screen 304 Stainless Steel Canvas Edge Mining Separation
Key Words :
wire screen panel, industrial wire mesh,Grommet Screen
Raw Material :
SS304,SS316,SS316L
Application :
Material Screening‌
Durability :
High Wear Resistance‌
Pacakge :
Carton or Wooden Box
Description
Rotex Compatible Grommet Screen 304 Stainless Steel Canvas Edge Mining Separation

For industries demanding both durability and precision, HUATAO Grommet Screens deliver unmatched performance. Designed to work flawlessly with Rotex® separators, these screens are built from high-quality stainless steel variants (304, 304L, 316, 316L), ensuring they hold up against corrosive substances and harsh chemicals—critical for mining, chemical, and even food processing sectors. Their edge reinforcement is a highlight: choose between black PU strips for industrial resilience, transparent PU strips certified by FDA and EU standards (EC 1935/2004, EU 10/2011) for safe food contact, or folded wire edges that thrive in temperatures over 80°C. This adaptability means they’re not limited to a single industry. With customizable mesh configurations—from 14 to 230 mesh counts, wire diameters ranging 0.0014–0.0090 inch, and open areas of 46%–76.4%—they can be fine-tuned for any separation task. Plus, pre-installed grommets make swapping out old screens quick and easy, reducing operational interruptions, while their durable construction ensures longer service life, offering excellent value over time.

Key Parameters
Parameter Specification
Mesh Material Stainless Steel 304, 304L, 316, 316L
Edge material Generally reinforced strips are made of PU, canvas, silica gel, etc.
Mesh type woven mesh
Mesh count 14-230
Wire diameter 0.0014-0.0090 inch
Open area 46.0%-76.4%
Detailed Specifications
Item Mesh Size Wire Size (in.) Microns Open Area %
1 14 0.009 1580 76.4
2 16 0.009 1360 73.3
3 18 0.009 1180 70.2
41 230 0.0014 74 46
Edge Type Options
Rotex Replacement Grommet Screen with 0.0014-0.0090 Inch Wire Diameter and 46%-76.4% Open Area for Mining Separation
Black PU-Strip Grommet Screen
Rotex Replacement Grommet Screen with 0.0014-0.0090 Inch Wire Diameter and 46%-76.4% Open Area for Mining Separation
Transparent PU-Strip Grommet Screen
Rotex Replacement Grommet Screen with 0.0014-0.0090 Inch Wire Diameter and 46%-76.4% Open Area for Mining Separation
180° Folded Edge Grommet Screen
Production Process
Rotex Replacement Grommet Screen with 0.0014-0.0090 Inch Wire Diameter and 46%-76.4% Open Area for Mining Separation
Packaging & Logistics
Wooden box package for secure shipping and handling.
Rotex Replacement Grommet Screen with 0.0014-0.0090 Inch Wire Diameter and 46%-76.4% Open Area for Mining Separation
Rotex Replacement Grommet Screen with 0.0014-0.0090 Inch Wire Diameter and 46%-76.4% Open Area for Mining Separation
Applications
Rotex Replacement Grommet Screen with 0.0014-0.0090 Inch Wire Diameter and 46%-76.4% Open Area for Mining Separation
