Specifications
Place of Origin :
Hunan, China
Brand Name :
ZH brand
Model Number :
E4000B
Certification :
ce
Packaging Details :
Waste Paper Recycling Machine to produce egg tray dish 4000 pecs per hour export packing
Supply Ability :
200 Set/Sets per Year Waste Paper Recycling Machine to produce egg tray dish 4000 pecs
Price :
Negotiation
MOQ :
1set
Delivery Time :
60-90days
Payment Terms :
L/C, T/T, D/A, D/P
Condition :
New
Product Type :
Egg Tray Machine
Processing Type :
Pulp Molding Machine, Pulp Molding Machine
Voltage :
380-440V
Power :
100KW
Dimension(L*W*H) :
21X2.12X4.2M
Weight :
30t
Warranty :
12 months
After-sales Service Provided :
Engineers available to service machinery overseas
Name :
Waste Paper Recycling Machine to produce egg tray dish
Production :
Egg Tray, Fruit Tray, Cup Carrier, Disposable Medical Care Products
Automation :
Fully Automatic
Capacity :
4000 PCS/hour
Dryer :
6 Layers
Raw material :
Waste Paper
Finished Products :
Egg Tray Egg Carton
Port :
Guangzhou
Description

Waste Paper Recycling Machine to produce egg tray dish 4000 pecs per hour

Pulp Molding Egg Box Forming Machine 100KW Waste Paper Recycling

4000

E4000B (full auto, Rotary, 6 layers drying line) specification list

Type of products

30-cell egg tray

12-cell egg carton/box

10-cell egg carton/box

6+6- cell egg carton/box

6-cell egg carton/box

Fruit tray

Coffee tray

capacity (PCS/HR)

4000

4000

4000

4000

8000

3000

5000

Remarks: The capacity calculation takes the production of 30 cavity egg trays as the standard.(Size 300X290MM, weight 70g)

The Power list (Auto 4000B1C)
NAME AND TYPE QUANTITY POWER
(KW)		 REMAKR
Pulping
System		 1 SY-100-710 Conveyor 1 3
2 ZSJD-3 Hydrapulper 1 55
3 ZSK-1.8 Vibration Screen 1 4
4 JB-160-210 Agitator 2 6 3kw/set
5 Stock Pump 2 8 4KW/SET
6 Water Pump 1 1 5.5
7 Water Pump 2 1 2.2
8 Water Pump 5 1 4
Forming
System		 9 XZ8-14040
Automatic Rotary
Forming Machine		 1 11
10 Filter 1 0.37
11 Water-ring Vaccum Pump 1 75
12 Air Compressor 1 30
13 Refrigerated Air Dryer 1 2
Drying
Systerm		 14 Drying Line 1 32.2
Stacking
System		 15 Finished Product Conveyor 1 0
16 Stacker 1 0
Total Power 238.27

Consumption List (Auto 4000B1C)
NO. DESCRIPTION CONSUMPTION PER HOUR REMARK
1 Waste Paper 300kg
2 Electricity 180kw
3 Water 1.5-2.5T
4 0# Diesel Oil 40-45kg choose anyone from the three
Natural Gas 45-55m³
LPG 35-45kg
5 Chemical
for Water Resistence		 1.5-2.0kg Solid Content
This data only for reference
The Calarific Value of the Fuel 10000K CARL/ kg for Diesel Oil Energy Consumption of No.4 is counted with these data.
8000K CARL/m³ for Natural Gas
10000k CARL/ kg for LPG
