Flame Retardant Plastic Flexible PVC Tubing Pipe For Wire Jacket
Flame Retardant Plastic Flexible PVC Tubing Pipe For Wire Jacket
Flame Retardant Plastic Flexible PVC Tubing Pipe For Wire Jacket
Flame Retardant Plastic Flexible PVC Tubing Pipe For Wire Jacket
Specifications
Model Number :
Big size PVC tubing
Certification :
SGS
Place of Origin :
China
MOQ :
1000meters
Price :
Negotiate
Payment Terms :
TT
Supply Ability :
50000meters /day
Delivery Time :
5-7days
Packaging Details :
Roll in paper carton
Working temperature :
-30 ºC~+105 ºC
color :
Grey
Materials :
PVC
Approval :
UL ROHS
ID Size :
1mm~30mm
Flammability :
VW-1
Voltage Rating :
300V 600V
Tensile Strength (Mpa ) :
≥10.41
Standard :
SGS
Thickness :
0.3mm~0.7mm
Packing :
Roll
Description

Flame Retardant Plastic Flexible PVC Tubing Pipe For Wire Jacket

Features:
1 .Material: Polyvinyl Chloride,


2. Working temperature: -30 ºC~+105 ºC


3. Flexible, Soft, Flame retardant


4. Color: Grey Black, clear, red, blue, green, etc.


5. Environmental standards: ROHS UL compliant

6. Inside diameter: 1mm~30mm

7. Voltage: 300V, 600V

8. 6.Flammability:VW-1


Product Features: Soft, has good electrical and physical properties, acid, corrosion resistance, stable performance, etc.


Applications: All kinds of electrical appliances, industrial appliances, lighting, automotive wiring harness, electronic components, motor leads, machinery, toys, stationery and other fields.

Technical Data:

Property Typical Performance
Yield Strength ≥10.41MPa
Breakage Elongation (%) ≥100%
Voltage 300V；600V
Flexibility Outstanding
Flame resistance VW-1


Dimensions:

I.D.(mm) Wall thickness(mm) Packing size (m/r)
WL-300 WL-600
0.80±0.1 0.25±0.05 0.40±0.05 500
1.0±0.1 0.30±0.05 0.40±0.05 500
1.5±0.1 0.33±0.05 0.45±0.05 400
2.0±0.2 0.33±0.05 0.50±0.05 400
2.5±0.2 0.35±0.05 0.50±0.05 300
3.0±0.2 0.40±0.05 0.50±0.05 300
3.5±0.2 0.40±0.05 0.50±0.05 300
4.0±0.2 0.45±0.05 0.55±0.05 300
4.5±0.3 0.45±0.05 0.55±0.05 300
5.0±0.3 0.45±0.05 0.55±0.05 300
6.0±0.3 0.45±0.05 0.55±0.05 300
7.0±0.3 0.45±0.05 0.55±0.05 150
8.0±0.35 0.45±0.05 0.55±0.05 150
9.0±0.35 0.50±0.05 0.60±0.05 150
10.0±0.35 0.55±0.10 0.65±0.10 150
11.0±0.40 0.55±0.10 0.65±0.10 150
12.0±0.40 0.55±0.10 0.65±0.10 150
13.0±0.40 0.55±0.10 0.65±0.10 150
14.0±0.40 0.55±0.10 0.65±0.10 150
15.0±0.40 0.60±0.10 0.70±0.10 50
16.0±0.40 0.60±0.10 0.70±0.10 50
17.0±0.40 0.60±0.10 0.70±0.10 50
18.0±0.40 0.60±0.10 0.70±0.10 50
19.0±0.40 0.65±0.10 0.75±0.10 50
20.0±0.50 0.65±0.10 0.75±0.10 50
21.0±0.50 0.65±0.10 0.75±0.10 50
22.0±0.50 0.70±0.10 0.80±0.10 50
23.0±0.50 0.70±0.10 0.80±0.10 50
24.0±0.50 0.75±0.10 0.85±0.10 50
25.0±0.50 0.75±0.10 0.85±0.10 50
26.0±0.50 0.85±0.10 0.85±0.10 50
