UL 2054 PLC Controlled Lithium Battery External Short Circuit Tester
UL 2054 PLC Controlled Lithium Battery External Short Circuit Tester
Specifications
Brand Name :
Gaoxin
Model Number :
GX-6055
Certification :
CE
Place of Origin :
China
MOQ :
1set
Price :
negotiation
Payment Terms :
FOB Shenzhen, T/T
Supply Ability :
50 sets per month
Delivery Time :
15-20 working days
Packaging Details :
Non-fumigation wooden box
Model :
GX-6055
Test Voltage :
100V
Test current :
1000A
Control Mode :
PLC
Warranty :
12 months
Dimension :
500x500x500mm
Description

High Precision Lithium Battery Cell Battery External Short Circuit Tester

Product Name:Battery short-circuit testing machine

Product Model:GX-6055

Test purpose: This test simulates an external short circuit

Requirement: Short circuit of positive and negative terminals of the battery shall not cause fire or explosion

Test standard:

IEC 62133, UN38.3, UL 2054, UL 1642, QC/T 744-2006, QC/T 743-2006,

7. Technical Parameter:

Working voltage

AC 220V 50Hz-60Hz

Impact voltage

AC 1kv/1.2-50μs(max)1min

Maximum testing voltage

100V~1000V

Dc response time

≤5μs

Maximum short circuit current

1000A

The device interior resistance

80±20mΩ

Action time

Response time / release time ≯30ms

Performance characteristic

Cold and voltage ≯66％Us

Cold release voltage ≯30％Us,≮5％Us

Operating Mode

Remote control within 7 meters without barrier

Explosion-proof case material

Inner case: SUS# 304 stainless steel sheet

Outer case: Cold-roll steel sheet with paint

Cotrol Mode

 PLC touch screen full-automatic control
Voltage,temperature, current collection External connected multi - channel data acquisition instrument or PLC data collection module, Channels are extended in Nx4 mode
Explosion-proof temperature Range RT + 10~200 ℃
Heat preservation material Efficient compression glass wool or Rigid polyurethane foam cotton
Temperature control accurcey 0.1℃
Temperature uniformity ± 2 ℃
Temperature luctuation ± 0.5 ℃
Explosion inner box size 500*500*500mm, 400*400*400mm, 500*600*500mm or customized
Short circuit Mode

RT Short circuit

high temperature short circuit

short circuit protection

high-low temperature short circuit
Operating ambient temperature temperature -10℃~100℃, humidity 10~90% no condensation
Power AC 220V± 10%, 50/60Hz, 380V ± 1%
Gas consumption 0.5~0.8MPa
