WNK 0.5V~4.5V I2C Temperature Pressure Sensor for Coffee Machine and Water Dispenser
WNK 0.5V~4.5V I2C Temperature Pressure Sensor for Coffee Machine and Water Dispenser
WNK 0.5V~4.5V I2C Temperature Pressure Sensor for Coffee Machine and Water Dispenser
WNK 0.5V~4.5V I2C Temperature Pressure Sensor for Coffee Machine and Water Dispenser
WNK 0.5V~4.5V I2C Temperature Pressure Sensor for Coffee Machine and Water Dispenser
WNK 0.5V~4.5V I2C Temperature Pressure Sensor for Coffee Machine and Water Dispenser
Specifications
Delivery Time :
5
Process connection :
M12x1,M10x1, customized
Protection class :
IP68 top-side potting
Brand Name :
WNK
Output :
0.5V~4.5V,I2C,(10%-90%Vcc ratio output)
Model Number :
WNK125PS
MOQ :
1
Pressure range :
0~5...50bar,(as requriement)
Accuracy :
±1% F.S.
Price :
25
Working temperature :
-20℃~80℃
Power supply :
5VDC,3.3~5VDC
Temperature signal :
NTC
Certification :
CE/ROHS
Storage temperature :
-30℃~95℃
Place of Origin :
China
Description



  • The WNK125SPT is a miniaturized diffused-silicon integrated pressure and temperature sensor capable of simultaneously measuring pressure and temperature. Thanks to its compact design, it helps engineers save valuable space during product development. This pressure sensor offers high temperature stability and measurement accuracy, and is primarily used in coffee machines, water dispensers, air conditioners, smart water meters, water pumps, and other applications

WNK 0.5V~4.5V I2C Temperature Pressure Sensor for Coffee Machine and Water Dispenser

WNK 0.5V~4.5V I2C Temperature Pressure Sensor for Coffee Machine and Water Dispenser

WNK 0.5V~4.5V I2C Temperature Pressure Sensor for Coffee Machine and Water Dispenser

WNK 0.5V~4.5V I2C Temperature Pressure Sensor for Coffee Machine and Water Dispenser

Are you manufacturer or trading company?
We are 22-year professional manufacturer of Pressure/ Level/ Temperature transmitters with 4~20mA, Hart, Profibus & FF protocols, pressure sensors with SPI, I2C, 4~20mA, 0.5~4.5V and etc, and electronic switches. We provide high quality products with high competitive factory price.
Whats your quality control system?
As an ISO9001:2015 certificated manufacturer, we have strict quality control system, and each product is done fatigue testing, calibration, temperature compensation before shipment. High quality is guaranteed.
Is there MOQ with your product?
We have no MOQ limits, 1pc for testing purpose is acceptable.
Can we print our logo on the products? Do you provide customized products?
Yes, we can print your logo on our products; OEM, ODM&customization are welcomed.
What is the warranty of your products? And after-sales service?
Our warranty time is 12 months after shipment, and our after-sales dpt will respond with your questions in 24hrs, remote instruction by PC network is always available.
What is lead time of your product?
We are factory, our lead time is always within 7 working days for products without customization, but lead time for flange products is a little longer.
