Product Description
An LPG tank, also known as an LPG cylinder or storage vessel, is engineered to store propane, butane, or a mixture of both in their liquid state, which is achieved by maintaining the gas at a high pressure. Depending on the uses of LPG, such tanks come in various shapes, sizes, and materials. They range from small portable cylinders for household use to large, fixed tanks for commercial or industrial purposes.
Product Parameters
Volume (m³) | Pressure (MPa) | Work Medium | Type | Weight (kg) | Size (D*H)mm |
5 |
0.8 |
liquid oxygen liquid nitrogen liquid argon |
Vertical or horizontal | 3412 | 2000*5130 |
10 | 5378 | 2100*7170 | |||
15 | 6415 | 2500*6912 | |||
20 | 8255 | 2500*8765 | |||
30 | 12899 | 2900*8870 | |||
50 | 18960 | 3100*12058 | |||
100 | 34480 | 3600*15947 | |||
5 |
1.6 | 3945 | 2000*5130 | ||
10 | 6787 | 2000*7845 | |||
15 | 8628 | 2400*7552 | |||
20 | 10744 | 2400*9371 | |||
30 | 14640 | 2700*10310 | |||
50 | 23370 | 3100*12058 | |||
5 |
2.16 |
liquid carbon dioxide | 4450 | 2000*5130 | |
10 | 6986 | 2100*7170 | |||
15 | 8810 | 2500*6912 | |||
20 | 11328 | 2500*8756 | |||
30 | 17961 | 2500*8875 | |||
50 | 26097 | 3200*11300 | |||
100 | 49627 | 3500*16870 |
Uses of LPG tanks
Liquefied petroleum gas can be used in a number of applications, which include:
· Heating (particularly popular in off-grid homes).
· Cooking appliances
· Alternative fuel for cars and other vehicles
· Refrigerant
· Industrial uses
Thus, just like the storage and transportation of LNG, LPG tanks are the most efficient way to deliver LPG and provide easy access to it.
LPG tanks in industry
A number of industries use LPG as an energy carrier. It’s also used as feedstock for the chemical synthesis of substances such as butene, propylene, ethylene and acrylic acid. Again, LPG tanks serve the purpose of facilitating the different industries’ access to this substance.
