Cryogenic Dewar Liquid Nitrogen Storage Cylinder 210l Pressure Vessel
Cryogenic Dewar Liquid Nitrogen Storage Cylinder 210l Pressure Vessel
Cryogenic Dewar Liquid Nitrogen Storage Cylinder 210l Pressure Vessel
Cryogenic Dewar Liquid Nitrogen Storage Cylinder 210l Pressure Vessel
Specifications
Brand Name :
mkimm
Certification :
ISO
Place of Origin :
henan
MOQ :
1
Price :
bargain
Payment Terms :
T/T,L/C,Paypal,Alipay,West Union and so on
Supply Ability :
25 every month
Delivery Time :
15days
Packaging Details :
wooden box
Condition :
New
Weight: :
360kg
Key Selling Points :
Easy to Operate
Capacity: :
210L
Dimension(L*W*H): :
516*516*1717mm
Description

Cryogenic Dewar Cylinder Liquid Nitrogen Storage Cylinder Cryogenic Liquid Storage Tank 210l Pressure Vessel

The DPL series containers are high performance vacuum insulated, it is designed to store and transport cryogenic liquid oxygen,nitrogen or argon. Containers can be used for over road transportation of cryogenic fluids, as well as on-site storage and supply in a wide range of applications in a long holding time, with self-Pressure built gas supply systems, these cylinders are capable of providing continuous flow rates of up to 9.2 cu.m/h. if you require a greater vaporizing volume, we can provide an external vaporizer.

Product Model
DPL-100
DPL-175
DPL-195
DPL-210
DPL-410
DPL-450
Diameter*Height(mm)
454*1247
508*1500
508*1620
508*1707
750*850*1770
750*850*1900
Working Pressure(MPa)
1.33
1.42.01
2.88
1.42.01
2.88
1.42.01
2.88
1.43.17
1.43.17
Pressure Relief Valve(MPa)
1.59
1.592.41
3.45
1.592.41
3.45
1.592.41
3.45
1.593.45
1.593.45
Inner Container Bursting Disc(MPa)
2.60
2.603.62
5.17
2.603.62
5.17
2.603.62
5.17
2.605.70
2.605.7
Maximum Liquid Capacity(L)
100
175
195
210
410
450
Usable Liquid Capacity(L)
95
166
185
197
389
427
Normal Evaporation Rate ((LN2))
≤2.1%
≤2.1%
≤2.1%
≤2.1%
≤1.8%
≤1.8%

Cryogenic Dewar Liquid Nitrogen Storage Cylinder 210l Pressure Vessel

FAQ

Q1.Are you manufacturer or trading company?

We are professional manufacturer in cryogenic equipment filed.
Q2.What's your advantage?
We provide you not only techology-leading,stable and reliable,cost-efficient equipment,but also solutionsand
after-sales service.
Q3.Have your engineers participated in any foreign projects?
Yes,our engineers have more than 30 years experience in this filed and have participated in the design,manufacurer,installation and comissioning of the equipment in Turkey,Russia,
