ST-60V High Accuracy Pneumatic Press Machine 60ton For Metal Sheet Stamping
ST-60V High Accuracy Pneumatic Press Machine 60ton For Metal Sheet Stamping
ST-60V High Accuracy Pneumatic Press Machine 60ton For Metal Sheet Stamping
ST-60V High Accuracy Pneumatic Press Machine 60ton For Metal Sheet Stamping
ST-60V High Accuracy Pneumatic Press Machine 60ton For Metal Sheet Stamping
ST-60V High Accuracy Pneumatic Press Machine 60ton For Metal Sheet Stamping
ST-60V High Accuracy Pneumatic Press Machine 60ton For Metal Sheet Stamping
ST-60V High Accuracy Pneumatic Press Machine 60ton For Metal Sheet Stamping
ST-60V High Accuracy Pneumatic Press Machine 60ton For Metal Sheet Stamping
ST-60V High Accuracy Pneumatic Press Machine 60ton For Metal Sheet Stamping
ST-60V High Accuracy Pneumatic Press Machine 60ton For Metal Sheet Stamping
ST-60V High Accuracy Pneumatic Press Machine 60ton For Metal Sheet Stamping
Specifications
Price :
$14,600/cases 1-2 cases
cnc or not :
Normal
machine type :
Punching Machine
slide stroke (mm) :
120
power source :
Pneumatic
place of origin :
Guangdong, China
brand name :
QIAOSEN
voltage :
380V
dimension(l*w*h) :
1595*1000*2800mm
motor power (kw) :
5.5
model number :
ST-60V
weight (t) :
5.6
key selling points :
High-Accuracy
warranty :
1 Year
machinery test report :
Provided
video outgoing-inspection :
Provided
core components :
Bearing, Pump, Gear, Motor, PLC, Pressure Vessel, Engine
punching capacity :
60ton
Slider adjustment amount :
75mm
Up platform area :
700*400*70mm
Down platform area :
900*500*80mm
Slider center to machine distance :
255mm
Platform to floor distance :
785mm
Main motor power :
5.5*4
Air pressure :
6
Punch dimension(L*W*H) :
1595*1000*2800mm
Punch weight :
5.6tons
Place of Origin :
China
Brand Name :
QIAOSEN
Certification :
CE / ISO14001
Description
ST-60V High-Accuracy Pneumatic Punching & Power Press Machine for Metal Sheet Stamping
This 60-ton open single point crank punching machine meets Japanese JIS 1 class standards for safety, energy efficiency, stability, automation, and high precision.
Performance Features
  • High-strength fuselage structure with minimal deformation and high precision
  • OMPI pneumatic dry clutch brake system
  • Slider with 2-corner and 6-sided guides
  • Slider guide features high-frequency quenching and rail grinding process for minimal wear, high precision, and extended service life
  • Crankshaft made of high-strength alloy 42CrMo (1.3 times stronger than 45 steel)
  • Copper sleeve made of tin phosphor bronze ZQSn10-1 (1.5 times stronger than ordinary BC6 brass)
  • Highly sensitive hydraulic overload protection device protects press and die service life
  • Optional mat (air cushion) available
ST-60V High Accuracy Pneumatic Press Machine 60ton For Metal Sheet Stamping
Technical Specifications
No Item Unit ST-60V
1 Punching capability ton 60
2 Impact force location mm 4
3 Slider strokes per minute SPM 35-90
4 Slider length mm 120
5 Max die shut height mm 310
6 Slider adjustment amount mm 75
7 Up platform area mm 700×400×70
8 Down platform area mm 900×500×80
9 Shank hole mm Ø50
10 Main motor power kw×p 5.5×4
11 Air pressure kg/cm² 6
12 Punch accuracy grade JIS 1
13 Slider adjustment device Manual operation
14 Slider center to machine distance mm 225
15 Platform to floor distance mm 785
16 Punch weight ton 5.6
17 Punch dimension (L×W×H) mm 1595×1000×2800
18 Die cushion capacity ton 3.6
19 Stroke mm 70
20 Active area mm² 350×300
Product Configuration
ST-60V High Accuracy Pneumatic Press Machine 60ton For Metal Sheet Stamping
Similar Products
ST-60V High Accuracy Pneumatic Press Machine 60ton For Metal Sheet Stamping ST-60V High Accuracy Pneumatic Press Machine 60ton For Metal Sheet Stamping ST-60V High Accuracy Pneumatic Press Machine 60ton For Metal Sheet Stamping ST-60V High Accuracy Pneumatic Press Machine 60ton For Metal Sheet Stamping ST-60V High Accuracy Pneumatic Press Machine 60ton For Metal Sheet Stamping ST-60V High Accuracy Pneumatic Press Machine 60ton For Metal Sheet Stamping
Company Profile
Dongguan Qiaosen Machinery Co., Ltd, with our own factory located in Jiangsu province, was established in 2016. Our location near Shanghai provides convenient transportation access. We are a hub of creative minds and gifted talents in machinery manufacturing.
Our factory was among the first to pass ISO9001:2008 quality management system certification. We specialize in hydraulic press machine production, offering machines from 10 tons to 2000 tons across 8 series with over 100 types. Our product range includes single column, four column, C-frame, H-frame presses, punching machines, folding machines, and cutting machines used in aviation, aerospace, automotive, shipbuilding, light appliances, and daily hardware industries.
Our products are known for exquisite design, competitive pricing, excellent quality, and efficient after-sales service and technical support. We serve customers across more than 20 domestic provinces and export to the United States, Japan, Russia, European Union, Southeast Asia, the Middle East, and other countries.
ST-60V High Accuracy Pneumatic Press Machine 60ton For Metal Sheet Stamping ST-60V High Accuracy Pneumatic Press Machine 60ton For Metal Sheet Stamping
Packing & Delivery
ST-60V High Accuracy Pneumatic Press Machine 60ton For Metal Sheet Stamping ST-60V High Accuracy Pneumatic Press Machine 60ton For Metal Sheet Stamping ST-60V High Accuracy Pneumatic Press Machine 60ton For Metal Sheet Stamping ST-60V High Accuracy Pneumatic Press Machine 60ton For Metal Sheet Stamping
Warranty and Service
  • One year warranty for the complete press machine
  • All spare parts available as most components are produced in our factory
  • Easy access to electrical parts using international famous brands
  • Technical training and consulting available via email, phone, or video
  • Engineer dispatch available for service, installation, or training with reasonable additional cost
  • English operation and maintenance manual provided with each press
  • Certificate of conformity included with each machine
Frequently Asked Questions
Who are we?
Our factory is located in Wuxi, China with a branch company in Dongguan, established in 2016. We export to Southeast Asia (50%), Mid East (30%), Africa (10%), South Asia (5%), Northern Europe (4%), and Eastern Europe (1%). Our team consists of 51-100 professionals.
Why select us?
We are a high-end quality punching machine manufacturer and guarantee customer satisfaction with our brand selection.
How about your delivery time?
Typically 25 to 40 working days after receiving advance payment.
Do you provide after-sale service?
Our technical and quality team provides continuous support whenever needed.
Can I order machines in different colors?
Yes, we can customize colors to match your production line requirements.
Can the touch screen language be changed?
Yes, we can provide interface languages including Spanish, French, and others according to your requirements.
