CA168-F Smart Prepaid Electricity Meter Anti-Tamper Single Phase Electric Meter With STS Encryption Algorithm
CA168-F Smart Prepaid Electricity Meter Anti-Tamper Single Phase Electric Meter With STS Encryption Algorithm
CA168-F Smart Prepaid Electricity Meter Anti-Tamper Single Phase Electric Meter With STS Encryption Algorithm
CA168-F Smart Prepaid Electricity Meter Anti-Tamper Single Phase Electric Meter With STS Encryption Algorithm
CA168-F Smart Prepaid Electricity Meter Anti-Tamper Single Phase Electric Meter With STS Encryption Algorithm
CA168-F Smart Prepaid Electricity Meter Anti-Tamper Single Phase Electric Meter With STS Encryption Algorithm
Specifications
Brand Name :
Calin
Model Number :
CA168-E
Certification :
CE/SABS/IEC
Place of Origin :
China
MOQ :
Negotiation
Price :
Negotiation
Payment Terms :
western Union,Paypal, T/T, L/C
Supply Ability :
70,000pcs per month
Delivery Time :
30 days
Packaging Details :
Carton
Product Name :
Anti tamper 1 phase low cost electric prepaid meter
Latch relay :
Build-in
Dimensions :
155x120x52mm
Weight :
750 g
wiring :
1 phase two wire LNNL
Accuracy :
Class 1
Terminal cover :
Extended flush type transparent
Data port :
Infrared optical
Description

The CA168-F is an advanced STS prepaid electricity meter, serving as an anti-tampering single-phase smart electric meter, an upgraded version of the original CA168 model. This compact device, which aligns with the BS footprint for prepayment systems, operates as both a smart energy meter and a credit management tool, complete with a keypad interface. It is designed to be cost-effective while packed with features, supporting various current ratings (5(80)A) and boasting a 30Vm RF withstand immunity, making it suitable for tough environmental conditions. It is perfect for low-voltage metering in residential and small commercial premises.

The meter features a robust metal backplate for secure mounting and enhanced resistance to tampering. Its polycarbonate, fire-resistant casing ensures durability in high-temperature conditions. Manufactured in strict adherence to ISO9001 standards and utilizing the STS encryption algorithm, this STS prepaid meter offers utilities a secure and dependable solution for revenue protection in the context of prepaid electricity services.

Major Features

a) Trip and alarm on tamper: cover open, reverse connection, neutral missing, etc.

b) Display latch relay status, tamper, low credit warning

c) Adjustable power limit and emergency credit

d) Bi-directional measurement

e) Display valuable meter information : V, A, P, balance

f) IP 54 rating

Utility benefits

1) Easy to deploy and maintenance

2) Increased tamper protection

3) Low operational cost

4) Optical port offers simple interrogation

5) Broad range of engineering settings

6) 15 year designed lifespan

Specifications:

Nominal voltage Un

220/230/240 V

Limited voltage

70%~120%Un

Nominal frequency fn

50-60Hz+5%

Basic current(Ib)

5-10A

Maximum current(Imax)

60-100A

Starting current(Ist)

20mA

Active energy constant

1000imp/kWh

Accuracy as Active energy to IEC62053‐21

Class1.0

Power consumption in Voltage circuit

<2W <8VA

Power consumption in current circuit

<1VA

Operating temperature

25℃ to+70℃

Storage temperature

40℃ to+85℃

Insulation level

4kV rms for 1min

Impulse voltage withstand

8kV, 1.2/50 μs

Air discharge

16kV

Immunity to HF fields

80MHz to 2GHz with load

10V/m

100kHz to 1GHz without load

30V/m

Fast transient burst test

4kV

Meter shell Protection Rate

IP54(IEC60529)

Insulation System Classification

Protective Class II
