Specifications
Brand Name :
Dingang
Model Number :
PPAL
Certification :
SGS,ITS,BV
Place of Origin :
China
MOQ :
1000 Kgs / 1 Metric Ton
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
100000 tons per year
Delivery Time :
30 workdays
Packaging Details :
Seaworthy Packing With Wooden Pallet
Product Name :
Prepainted Aluminum Coil
Alloy :
1050, 1100, 3003, 5052, 5050, 3104
Temper :
H1-H32, T3-T8
Thickness Paint Layer :
PVDF, More Than 25micron
Type of Coating :
PE or PVDF Mainly
Thickness Paint Layer PE :
More Than 18micron
Description

Product Description

Our PE/PVDF Coated Prepainted Aluminum Sheet is a high-performance building material specifically designed for metal roofing corrugated panels, available in two popular thicknesses—0.5mm and 0.7mm. Combining the lightweight and corrosion-resistant properties of aluminum with the superior protective and decorative performance of PE (Polyester) and PVDF (Polyvinylidene Fluoride) coatings, this product is widely used in various roofing projects, delivering excellent durability, aesthetic appeal, and cost-effectiveness. It is engineered to withstand harsh outdoor environments, reduce building load, and simplify installation, making it an ideal choice for residential, commercial, industrial, and public construction projects worldwide.

Specification

Item
Specification
Material
Aluminum Alloy (1060, 3003, 3004, 5052 optional)
Thickness
0.5mm, 0.7mm (customizable for special requirements)
Coating Type
PE (Polyester) Coating, PVDF (Fluorocarbon) Coating
Coating Thickness
PE: 15-25μm; PVDF: 20-30μm (primer + topcoat for PVDF)
Alloy Temper
H12, H14, H24, H26 (customizable based on project needs)
Width
1000mm, 1220mm, 1500mm (max 2650mm, customizable)
Length
2m-6m (customizable up to 12m for large-span projects)
Color
RAL color code, Pantone color, or custom color (matte, high-gloss,satin finishes optional)
Surface Finish
Smooth, wood grain, stone grain, or brushed (customizable)
Standards
ASTM, JIS, DIN, EN, ISO, GB, AAMA 2605 (for PVDF)
Certification
SGS, ITS, BV

Features & Advantages

1. Superior Coating Performance

PVDF Coating: Based on PVDF resin with fluorine content over 60%, featuring C-F bonds with bond energy up to 500 kJ/mol. It offers exceptional weather resistance, UV resistance, acid-alkali resistance, and salt spray resistance, maintaining stable color for over 20 years in harsh environments such as coastal high-salt-fog areas and industrial pollution zones. The coating has a pencil hardness of ≥2H, adhesion of ≥1 level, and excellent self-cleaning performance with low surface energy (18-22 mN/m), making pollutants hard to adhere.

PE Coating: Made of polyester resin, with good decorative performance, high gloss, and rich colors. It is cost-effective, with a service life of 10-15 years in temperate climates, suitable for general outdoor and indoor roofing projects. The coating adopts a single-layer baking process at 200-220℃, ensuring good processability and flexibility.

2. Optimal Thickness Design
3. Excellent Aluminum Substrate Properties
4. Easy Installation & Low Maintenance
5. Environmental Protection & Recyclability

Coating Performance Comparison

Performance Item
PE Coating
PVDF Coating
Weather Resistance (Outdoor Service Life)
10-15 Years
20-25 Years
UV Resistance (QUV Aging Test)
2000-3000 Hours
≥4000 Hours (Gloss Retention >90%)
Pencil Hardness
≥2H
≥2H (Better Wear Resistance)
Adhesion
≥1 Level
≥1 Level
Acid-Alkali & Salt Spray Resistance
Medium
Excellent (Suitable for Coastal/Industrial Areas)
Self-Cleaning Performance
General
Excellent
Cost Level
Economical (50%-70% of PVDF)
Higher (Premium Performance)

Application

Residential Buildings

Commercial Buildings

Industrial Buildings

Public Facilities

Special Environments

Production Process

Aluminum Substrate Selection: High-quality aluminum alloy coils are selected and inspected to ensure uniform thickness and stable performance.

Surface Treatment: The substrate is degreased, pickled, chromated, and dried to remove impurities and form a protective film, enhancing coating adhesion.

Coating Application: PE coating adopts single-layer roller coating; PVDF coating adopts double coating and double baking process (primer + topcoat), with precise control of coating thickness.

High-Temperature Curing: PE coating is cured at 200-220℃; PVDF coating is cured at 230-250℃ to form a stable and dense coating film.

Cooling & Cutting: The coated aluminum coil is cooled to room temperature, then cut into sheets of specified width and length according to customer requirements.

Quality Inspection: Each batch of products undergoes strict inspection (coating thickness, adhesion, color difference, flatness, etc.) to ensure compliance with standards.

FAQ

Q1: Can you provide customized colors and surface finishes?
A1: Yes, we support customization according to RAL color code, Pantone color, or customer-provided samples. Surface finishes such as matte, high-gloss, wood grain, and stone grain are also available.
Q2: What is the difference between PE and PVDF coatings? Which one should I choose?
A2: PE coating is cost-effective with good decorative performance, suitable for general outdoor projects in temperate climates. PVDF coating has superior weather resistance and corrosion resistance, suitable for harsh environments (coastal, industrial areas) and projects requiring long service life. You can choose according to your project location, budget, and service life requirements.
Q3: Can you provide samples?
A3: Yes, free samples (1-2 pieces) are available for quality inspection. The customer only needs to bear the shipping cost.
Q4: Can you customize the thickness, width, and length?
A4: Yes, we can customize thickness (0.3mm-3.0mm), width (30mm-2650mm), and length (2m-12m) according to your specific project needs.

Contact Us

If you are interested in our 0.5mm 0.7mm PE/PVDF Coated Prepainted Aluminum Sheet for Metal Roofing Corrugated Panels, or have any questions about product specifications, prices, or customization, please feel free to contact us. We will provide you with professional solutions and high-quality services.
