Specifications
Brand Name :
Dingang
Model Number :
Dingang - PPAL
Certification :
SGS,ITS,BV
Place of Origin :
China
MOQ :
1000 Kgs / 1 Metric Ton
Price :
Negotiable
Payment Terms :
L/C at sight or 30% T/T in advance as deposit,and 70% balance against the B/L copy
Supply Ability :
5000 Tons / Per Month
Delivery Time :
Within 30-45 Days
Packaging Details :
Seaworthy Packing With Wooden Pallet
Name :
Aluminum Coil for Gutter
Alloy :
3004
Thickness :
1.0MM
Width :
1220MM
Alloy or not :
Is Alloy
Application :
Construction Industry
Sample :
Available
Coating thickness :
PVDF:Not less than 25um PE:Not less than 18um
Recyclable :
Yes
Description


AA3004 H24 1.0MM PVDF Color Coated Aluminum Coil for Gutter

Engineered for superior performance in demanding drainage systems, our AA3004 H24 1.0mm PVDF color coated aluminum coil combines advanced alloy technology with premium surface protection, setting the standard for durability and functionality in gutter applications.



AA3004 H24 1.0MM PVDF Color Coated Aluminum Coil for Gutter



Product Parameters


Product Color Coated Aluminum Sheet/Prepainted Aluminium Coil
Thickness 0.1-1.6mm
Width 30-1600mm
Material 1050, 1060, 1100, 3003, 3004, 3105, 5052, 5005, 5754, 5083, 6061,8081 etc
Temper O, H12, H14, H16, H18, H24, H26, H32, H34, etc
Inner Diameter 405mm,505mm,150mm,etc.
Color RAL, Pantone Color Or As Alient's Demand
Coating thickness PVDF Paint Coating: Not Less Than 25um

PE Paint Coating : Not Less Than 18um
Packing Export Standard Wooden Pallets (Eye To Wall,Eye To Sky)
Payment Terms L/C at sight or 30% T/T in advance as deposit, and 70% balance against the B/L copy.
MOQ 3 Tons Per Specification
Delivery Time Within 30-45 Days
Loading Port Shanghai,Ningbo,Qingdao,Tianjin Port and Etc
Application Aluminum Roofing,ACP,Roller Shutter Window,Roller Shutter Door,Aluminum Ceiling,Aluminum Grilling,Aluminum Downspout System,Home Appliance's Plate, body tank of cold chain truck,high speed rail,aluminum pull ring,food packaging,outer packing case of capacitor,external contour of letter channel



Application Scenarios

Ideal for a wide range of architectural and industrial environments where corrosion resistance, structural strength, and long-term reliability are critical:


1.Commercial & Public Buildings

  • Airports, stadiums, and high-rise complexes with large-scale gutter systems requiring high load-bearing capacity and aesthetic consistency.

2.Industrial Facilities

  • Factories, power plants, and chemical plants exposed to harsh pollutants, moisture, or chemical emissions—resists sulfide, chloride, and acidic corrosion.

3.Coastal & Humid Regions

  • Coastal residences, marinas, and waterfront structures challenged by salt-laden air and high humidity; provides exceptional resistance to salt spray (proven via 1,500+ hours salt fog test).

4.Extreme Climate Zones

  • Areas with heavy snowfall, high winds, or temperature fluctuations—maintains structural integrity under dynamic loads (e.g., snow accumulation ≥50cm).

5.Architectural Gutters with Complex Designs


. Curved, decorative, or oversized gutters requiring excellent formability for precise bending and shaping without coating cracking.




AA3004 H24 1.0MM PVDF Color Coated Aluminum Coil for Gutter


Advantages

1.Superior Alloy Performance

2.Premium PVDF Coating System

3.Optimal Thickness for Heavy-Duty Applications

4. Corrosion Resistance Beyond Standards

5.Design Flexibility & Aesthetics
