Specifications
warranty :
1 year
customized support :
OEM
Place of Origin :
Henan, China
Brand Name :
Shengda
Model Number :
LXSK-15-25E
Flow Rate :
2.5m3/h
Measurement Range :
DN15-25
type :
Multi-jet meters, Prepaid water meters
material :
Nylon
Connectivity :
Threaded
Protection Class :
ip68
Product name :
Super plastic smart mechanical prepaid block water meter card reader
Size :
DN15-25
Pressure lose :
0.1mpa
Max water pressure :
less than 1MPa
Operating voltage :
3.0~3.6v
Water termperature :
0.1~30℃
Valve switch times :
more than 2000 times
Standard :
GBT 778
Internal lithium battery life :
3~5 years
Color :
Grey
Description
Super plastic smart mechanical prepaid block water meter card reader
Super Plastic Smart Mechanical Prepaid Block Water Meter Card Reader
Product Description
Super Plastic Smart Mechanical Prepaid Block Water Meter Card Reader
Super Plastic Smart Mechanical Prepaid Block Water Meter Card Reader
Super Plastic Smart Mechanical Prepaid Block Water Meter Card Reader
Super Plastic Smart Mechanical Prepaid Block Water Meter Card Reader
Specification
Item
Flow range
Q3
Q4
Q2
Q1
Min. reading
Max. reading
Q3/Q1
Q2/Q1
m3/h
m3
LXSK-15
80
1.6
2.5
3.125
0.05
0.03125
0.0001
999999
LXSK-20
80
1.6
4.0
5
0.08
0.05
0.0001
999999
LXSK-25
80
1.6
6.3
7.875
0.126
0.07875
0.0001
999999
LXSK-32
80
1.6
10
12.5
0.2
0.125
0.0001
999999
LXSK-40
80
1.6
16
20

0.2
0.0001
999999
LXSK-50
80
1.6
25
31.25
0.5
0.3125
0.0001
999999

Working conditions:

Flow range: Q1~Q3 (Q4 short time work not change error) Ambient temperature: 5℃~55℃ Ambient moisture: (0~93)%RH Water temperature: cold water meter 1℃~40℃, hot watr meter 0.1℃~90℃ Water pressure: 0.03MPa~1MPa (short time work 1.6MPa not leak, no damage) Pressure loss: ≤0.063MPa

Installation

Straight pipe length fore water meter is 10 times of DN, straight pipe length behind water meter is 5 times of DN. Flow direction should be the same as the arrow on the body directs.
Super Plastic Smart Mechanical Prepaid Block Water Meter Card Reader

Ordering precautions:

The smart water meter includes built-in batteries. Before placing an order, please communicate the details with the business manager. Please do not place order directly on the platform, as the smart product requires checking the specific product details and selecting a special channel freight forwarder for transportation.
The lead time on the website is inaccurate. Please communicate with our business manager to confirm the exact time.
Super Plastic Smart Mechanical Prepaid Block Water Meter Card Reader
Packing & Delivery
Super Plastic Smart Mechanical Prepaid Block Water Meter Card Reader
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
Company Profile
Super Plastic Smart Mechanical Prepaid Block Water Meter Card Reader
Super Plastic Smart Mechanical Prepaid Block Water Meter Card Reader
Super Plastic Smart Mechanical Prepaid Block Water Meter Card Reader
Super Plastic Smart Mechanical Prepaid Block Water Meter Card Reader
Super Plastic Smart Mechanical Prepaid Block Water Meter Card Reader
Super Plastic Smart Mechanical Prepaid Block Water Meter Card Reader
Till now our products are sold to over 130 countries over the world. We have some agents in other countries, 7 branches at home. Our products won very good reputation from customers at home and abroad.

Your coming and visit is warmly welcome!
FAQ
What's the payment term? We accept T/T, LC, WEST UNION, PAYPAL, CASH, Alipay, Wechat, etc. What's the delivery time ? Usually it depends on the requirements and quantity may take 10~30days around. What is the standard of package? Export standard package or special package according to customer requirement What kind of product quality your factory offer?
We offer most competitive prices with best quality Can you accept to use our logo? We accept OEM with your autherization. We want to know monthly capacity? 100000pcs/month, each product has different production capacity, we can talk details by email. Which market do you already sell? We already ship to Africa, Middle East, South America, Asia, etc. What kind of certificate you have? We have lSO, CE, MID, etc.
