Large-Span Prefabricated Steel Stadium, Fire Resistance Rating F60–F120 (60–120 min)
Large-Span Prefabricated Steel Stadium, Fire Resistance Rating F60–F120 (60–120 min)
Specifications
Workshop Crane Capacity :
up to 100 tons
Customization :
OEM/ODM; drawings by client or our in-house team
After-sales Service :
On-site erection guidance & technical support
Max. Single-piece Fabrication Height :
up to 6 meters （Assembly Height per Client's requirement & design drawings)
Max. Truss Segment Length :
up to 40 meters （Assembly Height per Client's requirement & design drawings)
Business Type :
Manufacturer (Original Factory)
Warranty :
12 months from B/L date; covering fabrication and material defects.
Steel Grade :
Q235B/Q355B (GB/T 1591); S355JR (EN 10025); ASTM A36 / A572 Gr50
Max. Single-piece Fabrication Weight :
up to 100 tons
Place of Origin :
China
Brand Name :
Shandong Xinghua Steel Structure
Certification :
EN1090 CE, ISO3834, ISO15614, AWS D1.1, ISO 9001/14001/45001
MOQ :
10 tons
Price :
USD/tonne (FOB Qingdao or any Chinese port of loading); final price subject to project drawings
Packaging Details :
Bundled, crated, rack-packed or nude (per member type); shipped by container load or breakbulk vessel.
Delivery Time :
20–25 days after drawing confirmation & deposit; subject to project scope and quantity.
Payment Terms :
T/T;30% or 50% deposit, balance before shipment to designated port.
Supply Ability :
min. 5,000 tons/month (80,000 tons/year)
Inspection :
SGS/BV/TÜV/Intertek, third-party accepted
Description

Large-Span Prefabricated Steel Stadium, Fire Resistance Rating F60–F120 (60–120 min)

Main Feature

The steel structure system of our stadium leverages state-of-the-art long-span spatial frame technology, which delivers outstanding seismic resistance and professional acoustic tuning via precise sound field regulation. This sophisticated engineered solution is highly adaptable to a wide range of sports competitions and high-end cultural shows, realizing efficient and flexible utilization of multi-functional venues with notable spatial adjustability.

Technical Specifications

Parameter

Specification

Standard

Structural Span

50-152 meters (Customizable)

GB 50017-2017

Audience Capacity

5,000-50,000 people

JGJ 31-2003

Seismic Resistance Level

Degree 8.5 Fortification

GB 50011-2010

Reverberation Time

1.5-2.2 seconds (Adjustable)

GB/T 50356-2005

Lighting Coefficient

≥2.8%

GB 50033-2013

Wind Resistance Level

Typhoon Level 12 (35m/s)

GB 50009-2012

Roof Live Load

≥0.5 kN/m²

GB 50009-2012

Fire Resistance Rating

F60-F120

GB 50016-2014

Design Service Life

52 years

GB 50068-2018

Key Advantages

  • Large-span spatial frame design creates column-free spaces for optimal event viewing perspectives

  • Professional acoustic optimization meets audio requirements for both sports events and cultural performances

  • Advanced seismic design ensures venue safety in earthquake-prone regions

  • Versatile adaptability enables quick transitions between different usage scenarios

Applications

  • Comprehensive Sports Complexes

  • Basketball and Volleyball Arenas

  • Badminton and Table Tennis Halls

  • Aquatic Centers and Water Sports Facilities

  • Gymnasiums and Martial Arts Halls

  • Indoor track and Field Training Facilities

  • Multi-purpose Sports Halls

  • School Sports Facilities
  • Community Sports Centers​
  • Professional Club Training Facilities
  • Competition and Event Venues
