Economic Prefabricated Workshop Prefab Steel Structure Farm Storage Warehouse Metal Building
Economic Prefabricated Workshop Prefab Steel Structure Farm Storage Warehouse Metal Building
Economic Prefabricated Workshop Prefab Steel Structure Farm Storage Warehouse Metal Building
Economic Prefabricated Workshop Prefab Steel Structure Farm Storage Warehouse Metal Building
Economic Prefabricated Workshop Prefab Steel Structure Farm Storage Warehouse Metal Building
Economic Prefabricated Workshop Prefab Steel Structure Farm Storage Warehouse Metal Building
Economic Prefabricated Workshop Prefab Steel Structure Farm Storage Warehouse Metal Building
Economic Prefabricated Workshop Prefab Steel Structure Farm Storage Warehouse Metal Building
Specifications
Brand Name :
TSIN
Model Number :
TSIN
Certification :
ISO, CE, SGS
Place of Origin :
Shandong, China
MOQ :
1000 sqm
Price :
USD 40-60 / sqm
Payment Terms :
T/T,L/C
Supply Ability :
100,000 sqm / month
Delivery Time :
25-40 Days
Packaging Details :
Packed on steel pallet with fixture and loaded into 40'HQ/OT
Type :
Portal Frame Structure
Project Solution Capability :
SketchUP/AutoCAD/PKPM/3D3S/TEKLA
Material :
Q235B/Q355B Steel
Main frame :
Welded H-shape Steel Beam
Welding method :
SAW, MIG,GMAW
Surface treatment :
Anti-corrosive paint or hot dipped galvanized
Life Time :
Main Structure 35-50 Years
Standard :
GB Standard
Material Grade :
Q355B, Q235B
Structure type :
Portal frame
Design Load :
Wind, Snow, Seismic
Design software :
PKPM, Tekla structures, CAD
Sand blasting :
Sa 2.5
Description
Economic Prefabricated Workshop Prefab Steel Structure Farm Storage Warehouse Metal Building
A modern commercial light warehouse designed for industrial-style garages, sheds, and storage needs. This customized steel structure warehouse utilizes prefabricated delivery solutions, with steel forming its primary load-bearing framework.
Product Specifications
Attribute Value
Type Portal Frame Structure
Project Solution Capability SketchUP/AutoCAD/PKPM/3D3S/TEKLA
Material Q235B/Q355B Steel
Main frame Welded H-shape Steel Beam
Welding method SAW, MIG, GMAW
Surface treatment Anti-corrosive paint or hot dipped galvanized
Life Time Main Structure 35-50 Years
Delivery Time 25-40 Days
Standard GB Standard
Material Grade Q355B, Q235B
Structure type Portal frame
Design Load Wind, Snow, Seismic
Design software PKPM, Tekla structures, CAD
Sand blasting Sa 2.5
Main Frame & Structural Components
The load-bearing main frame mainly consists of beams and columns. A comprehensive bracing system—including tie bars, knee braces, stay bars, column braces, and horizontal braces—works in conjunction with roof, wall, and floor systems to create a complete, robust steel structure.
Key Components
Main Steel Q355B, Q235B etc.
Frame type Portal frame, multi-story frame
Main frame Hot-rolled or Welded H beam and column, Q355B steel
Bracing components Tie bar, staying bar, Horizontal bracing, Column bracing
Cladding system Sandwich panel with glass wool, rock wool, PU insulation, Corrugated color steel sheet
Accessory Ridge tile, trim, Gutter, Down pipe, skylight, clerestory
Door Roll up door, industrial section door, swing door, Sliding door
Window PVC window, aluminum window, metal louver
Crane 5MT, 10MT, 15MT and more
Wall and Roof System
The roof panel typically runs as a single continuous length from eaves to ridge line. Wall panels are similarly continuous from bottom wall to eaves, constructed with 0.4mm-0.6mm thick corrugated metal sheets. For thermal insulation requirements, sandwich panels are available as an option.
Key Advantages
  • Superior material properties compared to wood and concrete
  • Precision manufacturing to strict specifications and tolerances
  • 100% recyclable materials
  • Resistant to warping, bending, and twisting with flexible design options
  • Enhanced building quality with reduced maintenance requirements
  • Improved safety and structural resistance
Construction Characteristics
Construction Period
Significantly faster than traditional methods with factory prefabrication and simple on-site assembly.
Environmental Protection
Minimal site disturbance, no water operations, and reduced dust pollution compared to concrete construction.
Cost Efficiency
20-30% lower construction costs than traditional buildings with superior durability and seismic performance.
Structural Weight
Lightweight design reduces overall building weight while maintaining structural stability.
Our Expertise
With extensive experience in delivering high-quality prefabricated steel structures, we provide comprehensive support throughout your project - from planning to construction.
