Specifications
Model Number :
ASTM A513
Brand Name :
Torich
Certification :
ISO9001:2008, TS16949
Place of Origin :
China
MOQ :
1000 kgs
Price :
600-1200
Payment Terms :
L/C,T/T
Supply Ability :
20000 tons per year
Delivery Time :
4-6 weeks
Packaging Details :
In bundles with seaworthy packing
Material :
Seamless carbon steel and alloy steel
Main Standard :
ASTM A519 / ASME SA519
Steel Grades :
1020, 1035, 1045, 4130, 4140; other grades available on request
Outside Diameter :
6–450 mm
Wall Thickness :
1–30 mm
Length :
1–12 m, custom cut length available
Heat Treatment :
HR, CW, SR, A, N; quenched and tempered condition available for alloy grades by agreement
Tube Shape :
Round standard; square, rectangular, and special sections available by agreement
Description

Seamless Carbon and Alloy Steel Mechanical Tubing, are produced according to technica standard of ASTM A519, with steel grade 1010, 1020, 1026, 4130,4140 etc

Size range: O.D.:6-450mm W.T.:1-30mm L:max12000mm

Steel Grade and Chemical Compositions:
Steel C Mn P S Si Cr Mo
Grade max 　 max max max min 　
1008 0.10 0.30-0.50 0.040 0.050 　 　 　
1010 0.08-0.13 0.30-0.60 0.040 0.050 　 　 　
1018 0.15-0.20 0.60-0.90 0.040 0.050 　 　 　
1020 0.18-0.23 0.30-0.60 0.040 0.050 　 　 　
1026 0.22-0.28 0.60-0.90 0.040 0.050 　 　 　
1035 0.32-0.38 0.60-0.90 0.040 0.050 　 　 　
1045 0.43-0.50 0.60-0.90 0.040 0.050 　 　 　
4130 0.28-0.33 0.40-0.60 0.040 0.040 0.15-0.35 0.80-1.10 0.15-0.25
4140 0.38-0.43 0.75-1.00 0.040 0.040 0.15-0.35 0.80-1.10 0.15-0.25

Grade condition Ultimat Yield Elongation Rockwell
　 　 Strength Strength 　 Hardness
　 　 ksi Mpa ksi Mpa % B Scale
1020 HR 50 345 32 221 25 55
　 CW 70 483 60 414 5 75
　 SR 65 448 50 345 10 72
　 A 48 331 28 193 30 50
　 N 55 379 34 234 22 60
1035 HR 65 448 40 276 20 72
　 CW 85 586 75 517 5 88
　 SR 75 517 65 448 8 80
　 A 60 414 33 228 25 67
　 N 65 448 40 276 20 72
1045 HR 75 517 45 310 15 80
　 CW 90 621 80 552 5 90
　 SR 80 552 70 483 8 85
　 A 65 448 35 241 20 72
　 N 75 517 48 331 15 80
4130 HR 90 621 70 483 20 89
　 SR 105 724 85 586 10 95
　 A 75 517 55 379 30 81
　 N 90 621 60 414 20 89
4140 HR 120 855 90 310 15 100
　 SR 120 855 100 689 10 100
　 A 80 552 60 414 25 85
　 N 120 855 90 621 20 100

Applications: for machinery, mechanical engineer
