DIN 2445-1 ST52 Hot Finished Seamless Steel Tube for Hydraulic Systems
DIN 2445-1 ST52 Hot Finished Seamless Steel Tube for Hydraulic Systems
DIN 2445-1 ST52 Hot Finished Seamless Steel Tube for Hydraulic Systems
DIN 2445-1 ST52 Hot Finished Seamless Steel Tube for Hydraulic Systems
DIN 2445-1 ST52 Hot Finished Seamless Steel Tube for Hydraulic Systems
DIN 2445-1 ST52 Hot Finished Seamless Steel Tube for Hydraulic Systems
DIN 2445-1 ST52 Hot Finished Seamless Steel Tube for Hydraulic Systems
DIN 2445-1 ST52 Hot Finished Seamless Steel Tube for Hydraulic Systems
DIN 2445-1 ST52 Hot Finished Seamless Steel Tube for Hydraulic Systems
DIN 2445-1 ST52 Hot Finished Seamless Steel Tube for Hydraulic Systems
Specifications
Brand Name :
TORICH
Model Number :
DIN 2445-1
Certification :
ISO 9001 ISO14001 TS16949
Place of Origin :
Zhejiang/China
MOQ :
1 Ton
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
60000 Ton/Tons per Year
Delivery Time :
20-40days
Packaging Details :
In bundles or in wooden boxes.
Standard2 :
DIN 2445-1
Thickness :
0.4 - 50 mm
Standard :
ASTM,DIN,GB,JIS
Grade :
ST30 ST35 ST45 ST52
Application :
Fluid Pipe
Section shape :
Round,Square
Alloy or not :
Is Alloy
Technique :
Hot Rolled,Cold Drawn,Cold Rolled
Secondary or not :
Non-secondary
Outer diameter(round) :
10 - 820 mm
Special pipe :
precision seamless pipe,seamless stainless steel tube
Material :
Carbon steel
Length :
5-12M or as your requirement
Usage :
hydraulic cylinder
Shape :
Square. Rectangular.Round
Product name :
Seamless steel tube
Surface :
Customers't Requirement
Description

DIN 2445-1 ST52 Hot Finished Seamless Steel Tube for Hydraulic Systems

DIN 2445-1 ST30 ST35 ST45 ST52 Hot Finished Seamless Tubing

Introduction

DIN 2445-1 is a standard that specifies the requirements for hot finished seamless steel tubes used in fluid dynamics systems. These tubes are essential in various applications due to their strength, durability, and resistance to pressure. This article will cover the material specifications, chemical composition, mechanical properties, and applications of ST30, ST35, ST45, and ST52 seamless steel tubes.

Material Specifications

The seamless tubes covered under DIN 2445-1 are produced from carbon steel and are designed to withstand high pressure and temperature conditions. The standard outlines the dimensions, tolerances, and manufacturing processes to ensure the quality and performance of the tubes.

Chemical Composition

The following table presents the typical chemical composition of the materials used in the production of ST30, ST35, ST45, and ST52 seamless steel tubes.

Grade Carbon (C) Manganese (Mn) Phosphorus (P) Sulfur (S) Silicon (Si)
ST30 0.12 - 0.20 0.30 - 0.60 ≤ 0.035 ≤ 0.035 ≤ 0.40
ST35 0.15 - 0.25 0.30 - 0.70 ≤ 0.035 ≤ 0.035 ≤ 0.40
ST45 0.20 - 0.30 0.40 - 0.70 ≤ 0.035 ≤ 0.035 ≤ 0.40
ST52 0.22 - 0.30 1.20 - 1.60 ≤ 0.025 ≤ 0.025 ≤ 0.40

Mechanical Properties

The mechanical properties of the seamless tubes are crucial for their performance in fluid dynamics systems. The following table summarizes the key mechanical properties for ST30, ST35, ST45, and ST52 grades.

Grade Yield Strength (MPa) Tensile Strength (MPa) Elongation (%) Hardness (HB)
ST30 ≥ 235 360 - 510 ≥ 24 ≤ 160
ST35 ≥ 275 410 - 550 ≥ 22 ≤ 170
ST45 ≥ 355 490 - 630 ≥ 20 ≤ 190
ST52 ≥ 450 600 - 800 ≥ 18 ≤ 210

Applications

The seamless steel tubes specified in DIN 2445-1 are widely used in various industries, including:

  • Hydraulic Systems: For transporting fluids under high pressure.
  • Pneumatic Systems: Used in applications requiring compressed air.
  • Oil and Gas Industry: For pipelines and drilling operations.
  • Automotive Industry: In the manufacturing of components that require high strength and durability.
  • Construction: For structural applications where seamless tubes are preferred for their integrity and performance.

DIN 2445-1 ST52 Hot Finished Seamless Steel Tube for Hydraulic Systems

DIN 2445-1 ST52 Hot Finished Seamless Steel Tube for Hydraulic Systems DIN 2445-1 ST52 Hot Finished Seamless Steel Tube for Hydraulic Systems

DIN 2445-1 ST52 Hot Finished Seamless Steel Tube for Hydraulic Systems DIN 2445-1 ST52 Hot Finished Seamless Steel Tube for Hydraulic Systems

DIN 2445-1 ST52 Hot Finished Seamless Steel Tube for Hydraulic Systems

DIN 2445-1 ST52 Hot Finished Seamless Steel Tube for Hydraulic Systems

TORICH Group, an one-stop service provider of raw materials engaged in raw material production, R&D and
trade, has 30+ years of experience in the market, exported to 56 +countries, and won good reputation and
credibility among domestic and foreign customers.
The company's production plant covers an area of over 10,000 square meters, with an annual production
capacity of 50,000 tons of materials and a comprehensive trading and warehousing capacity of 100,000 tons, which can satisfy customers' personalized needs for raw materials in terms of diversity and timeliness.
The group holds shares in more than ten domestic production entities, whose main products include
seamless steel pipes ( carbon steel and stainless steel), welded pipes ( carbon steel and stainless steel), pipe fittings ( carbon steel and stainless steel), titanium (titanium tubes, titanium rods, titanium cakes, titanium plates, etc.), aluminum (aluminum tubes, aluminum rods, aluminum die casting, aluminum casting, CNC machining), and CNC deep processing of metal materials such as tubes, rods, and casting parts.
Over the past 30 years, the company has been gradually developing new technologies and materials to meet
the growing needs of customers and various diversified needs, exporting to more than 56 countries and still
increasing the number of exporting countries, aiming to help customers to solve the demand for raw materials, and to facilitate one-stop purchasing for customers.

DIN 2445-1 ST52 Hot Finished Seamless Steel Tube for Hydraulic Systems

DIN 2445-1 ST52 Hot Finished Seamless Steel Tube for Hydraulic Systems

DIN 2445-1 ST52 Hot Finished Seamless Steel Tube for Hydraulic Systems

DIN 2445-1 ST52 Hot Finished Seamless Steel Tube for Hydraulic Systems

DIN 2445-1 ST52 Hot Finished Seamless Steel Tube for Hydraulic Systems

Q: Are you trading company or manufacturer ?

A: manufacturer,also can do trading.

Q: How long is your delivery time?

A: Generally speaking,it is 10-15 days if the goods are in stock,or it is 30-40 days if the goods are not in stock, it is according to quantity.

Q: Do you provide samples? is it free or extra ?

A: Yes, we could offer the sample for free charge but need pay the cost of freight.

Q: What is your terms of payment ?

A: Payment<=2000USD, 100% in advance. Payment>=2000USD, 30% T/T in advance ,balance before shippment.

If you have another question, pls feel free to contact with me.
