Automotive Precision Steel Tube En10305-1 6 - 350 Mm OD Max 12000mm Length
Automotive Precision Steel Tube En10305-1 6 - 350 Mm OD Max 12000mm Length
Automotive Precision Steel Tube En10305-1 6 - 350 Mm OD Max 12000mm Length
Automotive Precision Steel Tube En10305-1 6 - 350 Mm OD Max 12000mm Length
Automotive Precision Steel Tube En10305-1 6 - 350 Mm OD Max 12000mm Length
Automotive Precision Steel Tube En10305-1 6 - 350 Mm OD Max 12000mm Length
Automotive Precision Steel Tube En10305-1 6 - 350 Mm OD Max 12000mm Length
Automotive Precision Steel Tube En10305-1 6 - 350 Mm OD Max 12000mm Length
Automotive Precision Steel Tube En10305-1 6 - 350 Mm OD Max 12000mm Length
Automotive Precision Steel Tube En10305-1 6 - 350 Mm OD Max 12000mm Length
Automotive Precision Steel Tube En10305-1 6 - 350 Mm OD Max 12000mm Length
Automotive Precision Steel Tube En10305-1 6 - 350 Mm OD Max 12000mm Length
Specifications
Brand Name :
Torich
Model Number :
EN10305-1
Certification :
ISO 9001 ISO14001 TS16949
Place of Origin :
China
MOQ :
5tons
Price :
1200-1400USD/ton
Payment Terms :
L/C, T/T
Supply Ability :
5000tons per year
Delivery Time :
5-8 week days
Packaging Details :
In bundles
Material :
E355 E235 St52 16Mn 1045
Standard :
EN10305-1
OD :
6 - 350 mm
WT :
1 - 35 mm
Application :
Mechanical purpose
Length :
max 12000mm
Description

Precision Automotive Steel Tubes En10305-1 Ready to Honed steel pipes

Size range: O.D.:6-350mm W.T.:1-35mm L:max12000mm
Standard: EN10305-1 ASTM A519 GB/T3639 DIN2391 JIS G3445
Material:E235/ SAE1020/ SAE 1045 /10 # 20# 45#/ /DIN ST52/STKM 11A /STKM12B
Straightness:1/1000m
Tolerance: OD≤0.08mm WT:≤+/-0.15
Improve the precision with method: Cold drawn/DOM

Product Feature of precision cylinder 1020 honed steel pipe and tube:
1.High precision (can cut the costs of machining) .
2.Excellent surface finish
3.Good mechanical performance (Aneal ,Bright Anealing,QT heatment on steel tubes to reach customers' Mechanical requsts. )

Chemical composition %(Max)
C
Si
Mn

P

S
E235
0.22
0.55
1.60
0.025
0.025
SAE1020
0.18-0.23
0.30-0.60
0.04
0.05
SAE 1045
0.43-0.50
0.60-0.90
0.04
0.05
10 #
0.07-0.13
0.17-0.37
0.35-0.65
0.035
0.035
20#
0.17-0.23
0.17-0.37
0.35-0.65
0.035
0.035
45#
0.42-0.50
0.17-0.37
0.50-0.80
0.035
0.035
St52
0.22
0.55
1.6
0.25
0.025
STKM 11A
0.12
0.35
0.6
0.04
0.04
STKM12B
0.20
0.35
0.6
0.04
0.04


1.+C /BK No heat treatment after final cold drawing process.
2.+LC/BKW After the final heat treatment there's a suitable drawing pass.
3.+SA/BKS After the final cold drawing process there's a stress relief heat treatment in controlled atmosphere.
4.+A/GBK After the cold drawing process the tubes are annealed in a controlled atmosphere.
5.+N/NBK After the final cold drawing operation the tubes are normalized in a controlled atmosphere.

Annealing /+A/GBK Bright Annealing/+N/NBK

Items & Condition of precision hot rolled steel tube
Delivery: 30-45days
Payment : T/T. LC.Alibaba Tade Assurance Order
Packaging: In Hexagonal bundles ,Wooden boxes packaging.
Quantity tolerance: +/-10%
Marks on pipes(tubes): Standard,Steel Grade, Size, Heat No.( or at the buyer's option).
Mill Test Certificate:EN10204 3.1

Application:

. Automotive components. Tubes for structural applications
. Standard mechanical tubing
. Hydraulic Cylinder Applications
. Heavy Equipment And Agriculture

Automotive Precision Steel Tube En10305-1 6 - 350 Mm OD Max 12000mm LengthAutomotive Precision Steel Tube En10305-1 6 - 350 Mm OD Max 12000mm Length
