A789 UNS S31803 Super Duplex 2507 Oil Gas Stainless Pipe Coiled Tubing
A789 UNS S31803 Super Duplex 2507 Oil Gas Stainless Pipe Coiled Tubing
A789 UNS S31803 Super Duplex 2507 Oil Gas Stainless Pipe Coiled Tubing
A789 UNS S31803 Super Duplex 2507 Oil Gas Stainless Pipe Coiled Tubing
A789 UNS S31803 Super Duplex 2507 Oil Gas Stainless Pipe Coiled Tubing
A789 UNS S31803 Super Duplex 2507 Oil Gas Stainless Pipe Coiled Tubing
A789 UNS S31803 Super Duplex 2507 Oil Gas Stainless Pipe Coiled Tubing
A789 UNS S31803 Super Duplex 2507 Oil Gas Stainless Pipe Coiled Tubing
Specifications
Brand Name :
TORICH
Model Number :
A789 UNS S31803
Certification :
ISO9001, TS16949
Place of Origin :
CHINA
MOQ :
1tons
Price :
negotiable
Payment Terms :
T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability :
60000ton/year
Delivery Time :
45-60 days
Packaging Details :
in bundles with seaworthy packing, in wooden box
Product name :
A789 UNS S31803 Super Duplex 2507 Oil Gas Stainless Pipe Coiled Tubing
Standard :
ASTM A789
Technique :
Hot finish，cold finish
Section shape :
Round
Alloy or not :
Stainless
Secondary or not :
Non-secondary
Special tube :
Duplex Stainless Steel Pipe
Surface :
Annealed, brightly annealed, polish
Hea treatment :
Full or isothermal anneal
Description

A789 UNS S31803 Super Duplex 2507 Oil Gas Stainless Pipe Coiled Tubing

Manufacture:

Pipes shall be made by the seamless process and shall be either hot finished or cold finished.

Application:

high pressure pipe line, heat exchanger(chemical processing industry), oil and gas pipeline

Size Range:
OD:21.3-711mm

WT: SCH5/SCH10/SCH40/SCH80/SCH160/XXS(1.65mm-30.75mm)

Length: max 12000mm

Superior Surface Finish:

The traditional annealing:

Open furnace---Oxygen atmosphere---form Scale, tarnish the material, For more than 12m tubes

this method is hard to clean inner surface.

A special bright annealing:

Closed furnace---Intert atmosphere use noble gases(Nitrogen and argon) Preventing Oxygen to contact with material---Surface finish is clean, bright and precision, which is an excellent starting point for further process, like electro-polishing and mechanical polishing. For more than 12m tubes, this method is much cleaner smoother on both inner and outer surface.

Material:

Grade: Duplex 2205

Chemical Properties
C Si Mn P S Cr Ni Mo N
≤0.03 ≤1.00 ≤2.00 ≤0.04 ≤0.03 21.0~24.0 4.5~6.5 2.5~3.5 0.08~0.2

Mechanical Properties:

Mechanical Properties:
Ts (Mpa) El (%) Hv 2.0t/2B
≥ 450 ≥ 620 ≥ 18 ≤ 320

Packing:

Each tube in a plastic bag, then put tubes in a seaworthy woven bag ,each unit weight 400kg-500kg/bundle.

With strong wood structure box packing by containers loading and shipping.

Or as customer's requirement.


20 ft container - GP: 5.8m (Length) * 2.13m (Width) * 2.18m (Hight) ------ Max Gross Weight: 25MT/container.
40 ft container - GP: 11.8m (Length) * 2.13m (Width) * 2.18m (Hight) ------ Max Gross Weight: 27MT/container.
40 ft container - HG: 11.8m (Length) * 2.13m (Width) * 2.72m (Hight) ------ Max Gross Weight: 27MT/container.

Port Shanghai

Test:

  • PMI test
  • Hydraulic test
  • 100%Inner cleaned by sponge
  • 100%Dimension test
  • 100%Surface test

A789 UNS S31803 Super Duplex 2507 Oil Gas Stainless Pipe Coiled TubingA789 UNS S31803 Super Duplex 2507 Oil Gas Stainless Pipe Coiled Tubing
