Specifications
Brand Name :
TORICH
Model Number :
ASTM A209
Certification :
ISO 9001 ISO 14001 EN 10204.3.1 TS 16949 BV-MODE II
Place of Origin :
China
MOQ :
5 tons
Price :
800-2000 USD ton
Supply Ability :
6000 tons annual
Delivery Time :
30-60days after received your payment
Packaging Details :
Packed in bundles or wooden box or upon request
Product Name :
Carbon Molybdenum Seamless Steel Pipes
Material :
Carbon Molybdenum
Steel Grade :
T1，T1a,T1b
Application :
Boiler and Heat Exchanger
Diameter :
5-420mm
Wall thickness :
0.5-50mm
Standard :
ASTM A209
Production method :
Seamless cold drawn Hot Rolled Seamless
Description

ASTM A209/A209M Seamless Carbon-Molybdenum Alloy-Steel Boiler and Superheater Carbon Steel Heat Exchanger Tubes

Standard: ASTM A209 / A209M Seamless Carbon-Molybdenum Alloy-Steel Boiler and Super heater Tubes,Cold drawn and hot rolled seamless steel tubes for Boiler and Super heater

Applications: Boiler, Heat Exchanger, Cold Condensers

Size Range: OD:12.7-127mm WT:0.9-12.7mm

Steel Grade: T1, T1a, T1b

Manufacture:
Killed steel material.
The tubes are made by seamless process either hot-finished or cold-finished

Seamless Carbon-Molybdenum Alloy-Steel Boiler and Super heater Tubes
Cold drawn and hot rolled seamless steel tubes for Boiler and Super heater.

STEEL GRADE AND CHEMICAL COMPOSITIONS

Seel Grade

C

Mn

P

S

Si

Mo

T1

0.10-0.20

0.30-0.80

≤0.025

≤0.025

0.10-0.50

0.44-0.65

T1a

0.15-0.25

0.30-0.80

≤0.025

≤0.025

0.10-0.50

0.44-0.65

T1b

≤0.14

0.30-0.80

≤0.025

≤0.025

0.10-0.50

0.44-0.65

Mechanical Properties

Seel Grade

Tensile strength (Mpa)

Yield Strength (Mpa)

δfixed (Pipe Segment S≥8mm vertical)

δfixed

(S＜8mm vertical)

δfixed

(Round brilliant)

T1

≥380

≥205

≥30

See note

≥22

T1a

≥415

≥220

≥30

See note

≥22

T1b

≥365

≥195

≥30

See note

≥22

Note: S＜8mm vertical Elongation is the basic value minus 1.5%,per wall thickness minus 0.8mm

HARDNESS

Seel Grade

HB S ≥5.1mm

HRB S≤ 5.1mm

T1

≤146

≤80

T1a

≤153

≤81

T1b

≤137

≤77


Delivery condition and Heat treatment:
Cold Drawn Seamless and Hot Rolled Seamless need Heat treatment .minimum temperature is 650℃
If Delivery condition is annealing, isothermal annealing, normalizing+ tempering tempering minimum temperature is 650℃
Hot-finished tubes are heat treated at a temperature of 1200℉ (650℃) or higher.


Carbon Steel Heat Exchanger Tubes With Seamless Carbon - Molybdenum Alloy - Steel Carbon Steel Heat Exchanger Tubes With Seamless Carbon - Molybdenum Alloy - SteelCarbon Steel Heat Exchanger Tubes With Seamless Carbon - Molybdenum Alloy - Steel Carbon Steel Heat Exchanger Tubes With Seamless Carbon - Molybdenum Alloy - Steel

Reference Documents:
ASTM A450/A450M Specification for General Requirements for Carbon, Ferritic Alloy, and Austenitic Ally Steel Tubes

ASTM A941 Terminology Relating to Steel, Stainless Steel, Related Alloys and Ferroalloys
