ASTM A213 Stainless Steel Fin Tube 1100 Aluminum Fin Embedded In 304 Tube
ASTM A213 Stainless Steel Fin Tube 1100 Aluminum Fin Embedded In 304 Tube
ASTM A213 Stainless Steel Fin Tube 1100 Aluminum Fin Embedded In 304 Tube
ASTM A213 Stainless Steel Fin Tube 1100 Aluminum Fin Embedded In 304 Tube
ASTM A213 Stainless Steel Fin Tube 1100 Aluminum Fin Embedded In 304 Tube
ASTM A213 Stainless Steel Fin Tube 1100 Aluminum Fin Embedded In 304 Tube
ASTM A213 Stainless Steel Fin Tube 1100 Aluminum Fin Embedded In 304 Tube
ASTM A213 Stainless Steel Fin Tube 1100 Aluminum Fin Embedded In 304 Tube
Specifications
Brand Name :
Torich
Model Number :
ASTM A213
Certification :
ISO 9001 ISO14001 TS16949
Place of Origin :
China
MOQ :
5 m
Price :
negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
20000 Ton per Year
Delivery Time :
30-45 days after order confirmed
Packaging Details :
In plywood case, In wooden box.
Characteristic :
Finned Tube
Material :
ASTM A213, ASTM A179 etc
Production Method :
Seamless or welded
Package :
In bundles or as per requests
Finish :
Annealed
Length :
2-20m
Type :
Finned Tube
MTC :
EN10204.3.1
Description

Products Description:

ASTM A213 Stainless Steel Tube 1100 Al Fin Embedded in 304 Tube, Fin Tube

Steel Grade/Steel Material:
1. Standard: ASTM A178, ASTM A179, ASTM A192, ASME SA213, ASTM A106 etc
2. Fin Material: Aluminum, Copper Alloy, Stainless Steel, Carbon Steel

3. Base Tube: Copper, Aluminum, Steel, Monel, etc

STEEL GRADE AND CHEMICAL COMPOSITIONS
Seel Grade C Si Mn P S Ni Cr Mo etc
SUS 304TB 0.08max 1.00max 2.00max 0.040max 0.030max 8.00-11.00 18.00-20.00 - -
SUS 304HTB 0.04-0.10 0.75max 2.00max 0.040max 0.030max 8.00-11.00 18.00-20.00 - -
SUS 304LTB 0.030max 1.00max 2.00max 0.040max 0.030max 9.00-13.00 18.00-20.00 - -
SUS310TB 0.15max 1.50max 2.00max 0.040max 0.030max 19.00-22.00 24.00-26.00 - -
SUS310STB 0.08max 1.50max 2.00max 0.040max 0.030max 19.00-22.00 24.00-26.00 - 　
SUS 316TB 0.08max 1.00max 2.00max 0.040max 0.030max 10.00-14.00 16.00-18.00 2.00-3.00 -
SUS 316HTB 0.40-0.10 0.75max 2.00max 0.030max 0.030max 11.00-14.00 16.00-18.00 2.00-3.00 -
SUS316LTB 0.030max 1.00max 2.00max 0.040max 0.030max 12.00-16.00 16.00-18.00 2.00-3.00 -
SUS316TiTB 0.080max 1.00max 2.00max 0.040max 0.030max 10.00-14.00 16.00-18.00 2.00-3.00 Ti:5*C %max
SUS317TB 0.080max 1.00max 2.00max 0.040max 0.030max 11.00-15.00 18.00-20.00 3.00-4.00 -
SUS317LTB 0.030max 1.00max 2.00max 0.040max 0.030max 11.00-15.00 18.00-20.00 3.00-4.00 -
SUS347TB 0.080max 1.00max 2.00max 0.040max 0.030max 9.00-13.00 17.00-19.00 - Nb:10*C %max
SUS347HTB 0.40-0.10 1.00max 2.00max 0.030max 0.030max 9.00-13.00 17.00-20.00 - Nb:8*C %-1.00


Finned: Extruded fin, Spiral fin, Embedded G fin, Low fin, H fin, L fin etc

Size Range:

Bare tube OD: 8-51mm
Fin pitch: 1.6-10mm
Fin height: less than 17mm

Fin thickness: 0.2-0.4mm
Tube length: 2-20m

Steel Tube Characteristic:
High Anti-corrosion
Anti-wear
Lower Contact Resistance
Higher Stability
Ability to Prevent Dust
TORICH QUALITY ASSURANCE

Application:

Air Cooler, Charge Air Chiller, Condenser, Evaporator, Fluid Cooler, Gas Cooler, Oil Cooler, Radiator, Refrigeration, Steam to Air Heat Exchange, super heater etc.

Production Steel Tube:

ASTM A213 Stainless Steel Fin Tube 1100 Aluminum Fin Embedded In 304 Tube

ASTM A213 Stainless Steel Fin Tube 1100 Aluminum Fin Embedded In 304 Tube

Application:

ASTM A213 Stainless Steel Fin Tube 1100 Aluminum Fin Embedded In 304 Tube
