Seamless Cold Drawn Precision Pipe
Seamless Cold Drawn Precision Pipe
Seamless Cold Drawn Precision Pipe
Seamless Cold Drawn Precision Pipe
Seamless Cold Drawn Precision Pipe
Seamless Cold Drawn Precision Pipe
Seamless Cold Drawn Precision Pipe
Seamless Cold Drawn Precision Pipe
Seamless Cold Drawn Precision Pipe
Seamless Cold Drawn Precision Pipe
Specifications
Delivery Condition :
+C, +LC, +SR, +A, +N
Model Number :
EN10305-1
Steel Material :
E235 , E255 , E355
MOQ :
1 tons
Delivery Time :
45 days
Advantage :
High Precision
Payment Terms :
T/T
Process :
Cold Drawn
Price :
Negotiation
OD Size :
6-88mm
Certification :
ISO9001,TS16949
Surface :
Bright and clean
Supply Ability :
3000 tons/month
Product Name :
Cold Drawn Seamless Pipe
Brand Name :
Pipeway
WT Size :
1-15mm
Place of Origin :
China
Packaging Details :
Bundles Package, Wooden Box Package
Description

Cold Drawn Carbon Seamless Precision Pipe E355 +N / E235 +N EN10305-1
Material: E235, E255, E355 etc
Size Range: OD: 6-88mm, WT: 1-25mm, Length: 5.8m/6m, maximal 11.8m
Delivery Condition: +C, +LC, +SR, +A, +N


Application:

Fuel injection Pipe, Oil flow pipeline Automobile and motorcycle Shock Absorber Pipe
Seat lifter Pipe Hydrau-cylinder Pipe
Bicycle frame steel pipes Mechanical steel pipes for auto and motor parts
Auto and Motorcycle Parts Exhaust Pipe for Generator
High Heels Steel Pipes Campanula Seamless Steel Pipe
Bike and Bicycle Frame Hydraulic System(Oil Pipeline, Motor Engine Pipe)
Sewing machine and textile machine parts Air conditioning fitting
Gas oil burner pipe Oil pipe drilling
Auto and motor pipe fittings Gas Spring pipe,motor casing pipe


Quality Control:
1. Incoming Raw Material Inspection
2. Raw Material Segregation to avoid steel grade mix-up
3. Heating and Hammering End for Cold Drawing
4. Cold Drawing or Cold Rolling, On line inspection
5. Heat Treatment:+SR, +A, +N
6. Straightening/Cutting to specified length/Finished Measuring Inspection
7. Quality Testing in own lab with Tensile Strength, Yield Strength, Elongation, Hardness, Straightness, etc.
8. Packing and Stocking.

100% Eddy Current Testing.
100% Size Tolerance Checking.
100% Tube surface checking to avoid surface defects.


Product Name EN10305-1 E235 E255 E355 Seamless Cold Drawn Steel Tube
Material E235, E255, E355
Delivery Condition +C, +LC, +SR, +A, +N
Standard EN10305-1
Size Range OD: 6-88mm, WT: 1-15mm
Application High precision purpose, auto parts, oil cylinder, etc
Round Billet Bao Steel, Xingcheng Steel, Zhongtian Steel
Keyword Seamless Steel Tube
Certificate TS16949, ISO 9001
HS code 7304319000
Delivery Time 45 days
Pakcing Bundles or Woodern Boxes


Steel Grade Chemical Composition
Symbol Material Number

C

Max.

Si

Max.

Mn

Max.

P

Max.

S

Max.
E235 1.0308 0.17 0.35 1.20 0.025 0.025
E255 1.0408 0.21 0.35 0.40--1.10 0.025 0.025
E355 1.0580 0.22 0.55 1.60 0.025 0.025


Steel Grade +C +LC +SR
Name No.

Rm

Mpa

A

%

Rm

Mpa

A

%

Rm

Mpa

ReH

Mpa

A

%
E235 1.0308 480 6 420 10 420 350 16
E255 1.0408 580 5 520 8 520 375 12
E355 1.0580 640 4 580 7 580 450 10


Steel Grade +A +N
Name No.

Rm

Mpa

A

%

Rm

Mpa

ReH

Mpa

A

%
E235 1.0308 315 25 340--480 235 25
E255 1.0408 390 21 440--570 255 21
E355 1.0580 450 22 490--630 355 22


Seamless Cold Drawn Precision Pipe

Seamless Cold Drawn Precision Pipe

Tags: Precision Pipe, Carbon Preicision Steel Pipe, Steel Pipe, E355 +N, EN10305-1 E355 +N, automotive steel pipe
