5kgs HS705 Hydraulic Pressure Comparison Pump with 0-700bar Pressure Range
5kgs HS705 Hydraulic Pressure Comparison Pump with 0-700bar Pressure Range
5kgs HS705 Hydraulic Pressure Comparison Pump with 0-700bar Pressure Range
5kgs HS705 Hydraulic Pressure Comparison Pump with 0-700bar Pressure Range
5kgs HS705 Hydraulic Pressure Comparison Pump with 0-700bar Pressure Range
5kgs HS705 Hydraulic Pressure Comparison Pump with 0-700bar Pressure Range
5kgs HS705 Hydraulic Pressure Comparison Pump with 0-700bar Pressure Range
5kgs HS705 Hydraulic Pressure Comparison Pump with 0-700bar Pressure Range
Specifications
Place of Origin :
Beijing, China
Brand Name :
Sino Instruments
Model Number :
HS705
pressure range :
(0~700)bar
Brand :
huaxin
Work medium :
25#Transformer Oil
Connector :
M20X1.5
warranty :
1 Year
weight :
5kgs
Port :
Fob Beijing
Supply Ability :
500 Piece/Pieces per Month
Price :
$600.00 - $1,200.00/pieces
MOQ :
1 unit
Description
Product Description

HS705 Hydraulic comparator adopts advanced stainless steel and aluminum alloy special process.The lead screw design makes the high pressure operation more easy and save labor,the F-adjust valve adjust the exact pressure value.A detachable oil cup is easy to clean and maintenance,user could check the work medium timely from the transparent oil cover. Two standard pressure outputs are easy to connect gauges under test without using the wrenches.It widely calibrates pressure instruments in field and laboratory

5kgs HS705 Hydraulic Pressure Comparison Pump with 0-700bar Pressure Range

5kgs HS705 Hydraulic Pressure Comparison Pump with 0-700bar Pressure Range

Function

HS705 provides pressure for calibrating pressure gauges,such as pressure (different pressure) transducers,precision pressure gauges,general pressure gauges and other

pressure gauges.It can be widely used in power,chemical,

petrol, metallurgy, metering,military industry,etc.

Characteristics

l Compact dimension,light weight

l Portable structure

l Pressure range to 700bar

l Easy operation,saving labor

l Fast connection,quick pressurizing

l Increasing pressure easily,convenient maintenance

l The appearance is simple & beautiful

Technical Spec

Model:HS705 Hydraulic comparator

Generated pressure range:(0~70)MPa

Working media:25#transformer oil

Adjust resolution:0.001bar(0.1kPa)

Material:Stainless Steel/Aluminium for body;Stainless steel for outputs;Buna-N for seals

Output interface connection:M20×1.5Female

Package:Carrying black bag.Specialized cartons and foam wrarp(optional)

Dimensio5.2kgs

FAQ

1. What's the warranty?

1 year since you receive the instrument.

2. Lead time:

2-3 weeks after gettting payment.

3. Package:

By paper carton with foam or plywood with foam.

4.Shipping:

By DHL, Fedex, TNT, EMS and others.

5. Payment:

T/T, paypal, Western Union, Trade assurance.
