M20X1.5 Connector HS703 Pneumatic Type Pressure Calibration Pump with 60bar Pressure
M20X1.5 Connector HS703 Pneumatic Type Pressure Calibration Pump with 60bar Pressure
M20X1.5 Connector HS703 Pneumatic Type Pressure Calibration Pump with 60bar Pressure
M20X1.5 Connector HS703 Pneumatic Type Pressure Calibration Pump with 60bar Pressure
M20X1.5 Connector HS703 Pneumatic Type Pressure Calibration Pump with 60bar Pressure
M20X1.5 Connector HS703 Pneumatic Type Pressure Calibration Pump with 60bar Pressure
M20X1.5 Connector HS703 Pneumatic Type Pressure Calibration Pump with 60bar Pressure
M20X1.5 Connector HS703 Pneumatic Type Pressure Calibration Pump with 60bar Pressure
M20X1.5 Connector HS703 Pneumatic Type Pressure Calibration Pump with 60bar Pressure
M20X1.5 Connector HS703 Pneumatic Type Pressure Calibration Pump with 60bar Pressure
M20X1.5 Connector HS703 Pneumatic Type Pressure Calibration Pump with 60bar Pressure
M20X1.5 Connector HS703 Pneumatic Type Pressure Calibration Pump with 60bar Pressure
Specifications
Place of Origin :
Beijing, China
Brand Name :
SINO INTSTRUMENTS
Model Number :
HS703
Name :
HS703 pneumatic type pressure calibration pump
pressure range :
(-0.95~ 60) bar
Type :
Pneumatic
Working place :
Laboratory&Field
Medium :
Air
Connector :
M20X1.5
WEIGHT :
2.6KG
Size :
286L*198W*140H (mm)
Adjust resolution :
0.1mbar
Material :
Stainless steel /Aluminium
Packaging Details :
standard package
Port :
beijing port
Supply Ability :
300 Piece/Pieces per Month HS703 pneumatic type pressure calibration pump
Price :
$500.00 - $1,000.00/pieces
MOQ :
1 unit
Description

HS703 pneumatic type pressure calibration pump

Description

HS703 pneumatic type pressure calibration pump is made up of lead screw; relieve valve, reversing valve, and output interface.

Functions


HS703 pneumatic type pressure calibration pump can supply pressure for calibrating pressure gauges, Such as pressure (differential pressure) transducers, precision pressure gauges, general pressure gauges and other pressure gauge.

HS703 pneumatic type pressure calibration pump is portable structure and designed to generate pressure from vacuum to 60bar. Built-in filter protects the pump from dirty and make maintenance easy and convenient. The F-adjust valve could accomplish 10Pa (0.1mbar) pressure resolution. Especially the lever lead screw design makes user operate in economize labor. the design of reverse valve makes the switch of vacuum and positive pressure more smooth. Two standard pressure outputs are easy to connect gauges under test without using the wrenches. It widely calibrates pressure instruments in field and laboratory.

Technical Specification

Pressure range

(-0.95~ 60) bar

Accuracy

0.05% F.S

Pressure-transmitting media

air

Output interface

M20×1.5 Female

Overall Dimensions

325×210×170mm

Weight

2.6Kg

M20X1.5 Connector HS703 Pneumatic Type Pressure Calibration Pump with 60bar PressureM20X1.5 Connector HS703 Pneumatic Type Pressure Calibration Pump with 60bar PressureM20X1.5 Connector HS703 Pneumatic Type Pressure Calibration Pump with 60bar PressureM20X1.5 Connector HS703 Pneumatic Type Pressure Calibration Pump with 60bar Pressure

Packaging & Shipping

M20X1.5 Connector HS703 Pneumatic Type Pressure Calibration Pump with 60bar Pressure


Send your message to this supplier
Send Now

M20X1.5 Connector HS703 Pneumatic Type Pressure Calibration Pump with 60bar Pressure

Ask Latest Price
Product Detail
Place of Origin :
Beijing, China
Brand Name :
SINO INTSTRUMENTS
Model Number :
HS703
Name :
HS703 pneumatic type pressure calibration pump
pressure range :
(-0.95~ 60) bar
Type :
Pneumatic
Contact Supplier
M20X1.5 Connector HS703 Pneumatic Type Pressure Calibration Pump with 60bar Pressure
M20X1.5 Connector HS703 Pneumatic Type Pressure Calibration Pump with 60bar Pressure
M20X1.5 Connector HS703 Pneumatic Type Pressure Calibration Pump with 60bar Pressure
M20X1.5 Connector HS703 Pneumatic Type Pressure Calibration Pump with 60bar Pressure
M20X1.5 Connector HS703 Pneumatic Type Pressure Calibration Pump with 60bar Pressure
M20X1.5 Connector HS703 Pneumatic Type Pressure Calibration Pump with 60bar Pressure

Huaxin Instrument (Beijing) Co., Ltd.

Verified Supplier
2 Years
beijing, beijing
Since 2008
Business Type :
Manufacturer, Trading Company
Main Products :
Pneumatic Pressure Calibration Pump, Hydraulic Pressure Calibration Pump, Intelligent Pressure Calibrator
Total Annual :
10000000-50000000
Employee Number :
101~200
Certification Level :
Verified Supplier
