S71903 ACD/HCP4A Super Precision Angular Contact Ball Bearing with P4A Precision Grade and Hybrid Ceramic Balls for High Speed 56,000 rpm
S71903 ACD/HCP4A Super Precision Angular Contact Ball Bearing with P4A Precision Grade and Hybrid Ceramic Balls for High Speed 56,000 rpm
Specifications
Structure :
Angular Contact
Brand Name :
CNBTZC or OEM
Model Number :
S71903 ACD/HCP4A
Certification :
IATF16949:2016
Place of Origin :
China
MOQ :
1000
Price :
Please contact us,thanks
Payment Terms :
L/C,T/T
Supply Ability :
500000pcs per month
Packaging Details :
plastic bag,box,carton,pallet
Part Number :
S71903 ACD/HCP4A Angular Contact Ball Bearing
Lubrication :
Grease
Design :
High-capacity D
Coating :
Without
Sealing :
Without
Delivery Time :
30 days
Contact type :
Normal contact (two-point contact)
Replaceable With :
SKF, NSK S7903A5SN24TRV1VP4
Seals Type :
Sealed,Seal on both sides,2RZ
Ring type :
One-piece inner and outer rings
Description
S71903 ACD/HCP4A Super Precision Single Row Angular Contact Ball Bearing 7903 2RZ
S71903 ACD/HCP4A 17×30×7 mm Super Precision High Capacity Single Row Angular Contact Ball Bearing Hybrid Ceramic Balls High Speed
Super-precision, high-capacity, single row angular contact ball bearing with seals. The S71903 ACD/HCP4A bearing features precise dimensions, high static load capacity, P4A precision grade, and hybrid ceramic balls, delivering superior performance and reliability for applications requiring high rotational accuracy and stability.
Technical Specifications
Part Number S71903 ACD/HCP4A
Bearing Type Angular Contact
Measurement Unit Metric
Inner Bore Diameter (d) 17 mm
Inner Bore Diameter Tolerance -0.004mm to 0
Outer Bore Diameter (D) 30 mm
Outer Bore Diameter Tolerance -0.005mm to 0
Width (B) 7 mm
Width Tolerance -0.2mm to 0
Contact Angle 25° (15°,40° Available)
Material Hybrid (Chrome Steel Rings, Ceramic Balls)
Cage Material Phenolic
Number of Rows 1 Single Row
Seal Type Seal on both side
Temperature Range -30°C to 150°C
Lubrication Grease
Tolerance Class P4A better than P4 (ABEC-7)
Weight 0.015 kg
Dynamic Radial Load 3970 N
Static Radial Load 2000 N
Reference Speed For Grease 56,000 rpm
Limiting Speed For Oil 90,000 rpm
S71903 ACD/HCP4A Super Precision Angular Contact Ball Bearing with P4A Precision Grade and Hybrid Ceramic Balls for High Speed 56,000 rpm S71903 ACD/HCP4A Super Precision Angular Contact Ball Bearing with P4A Precision Grade and Hybrid Ceramic Balls for High Speed 56,000 rpm
Performance Features
  • Very tight tolerances suitable for precise machinery
  • Ability to handle both radial and axial loads simultaneously
  • High-speed operation with stability
  • Low torque and friction for energy efficiency
  • Enhanced rigidity for accuracy under heavy loads
  • Durability with extended service life
  • Effective performance across a wide temperature range
Applications
The S71903 ACD/HCP4A bearing, distinguished by its superior performance and precision, is widely used in various industrial applications including:
  • Metal cutting machine tools (machining centers, high-speed milling and grinding machines)
  • Robotics (delicate operations and semiconductor fault detection)
  • Printing machinery
  • Measurement devices
  • Marine gyro stabilizers
  • High-performance automotive components (race car wheel hubs)
Its ability to provide high rotational accuracy, stability, and durability under demanding conditions makes it essential for enhancing efficiency, precision, and safety across these diverse sectors.
Certifications: RoHS & REACH, IATF16949:2016
Features: High Speed and Stiffness, High Running Accuracy, High Load Carrying Capacity
Services: OEM&ODM Customized Services, Online Support, Professional Service
Sizes: Standard sizes available, custom sizes upon request
Factory Manufacturer: Yes
