6702 2RS Deep Groove Ball Bearing 15mm x 21mm x 4mm Thin Section Robot Bearing with Double Seals and High-Speed Capability
6702 2RS Deep Groove Ball Bearing 15mm x 21mm x 4mm Thin Section Robot Bearing with Double Seals and High-Speed Capability
6702 2RS Deep Groove Ball Bearing 15mm x 21mm x 4mm Thin Section Robot Bearing with Double Seals and High-Speed Capability
6702 2RS Deep Groove Ball Bearing 15mm x 21mm x 4mm Thin Section Robot Bearing with Double Seals and High-Speed Capability
Specifications
Clearance :
Standard
Interchange :
FAG NTN ....
Brand Name :
CNBTZC or OEM
Model Number :
6702 2RS
Certification :
IATF16949:2016
Place of Origin :
China
MOQ :
50000
Price :
Please contact us,thanks
Payment Terms :
L/C,T/T
Supply Ability :
500000pcs per month
Delivery Time :
2-4 weeks
Packaging Details :
plastic tub/middle box,carton,pallet
Bearing Seals :
Double Sealed - Seals on Two Sides,ZZ or Open available
Model Numbers: :
6702 2RS,6702-2RS, Deep Groove Ball Bearings
Description
6702 2RS Deep Groove Ball Bearings 15mm × 21mm × 4mm Thin Section Robot Bearing 61702 2RS
Product Overview

The 6702 ZZ deep groove ball bearing, with dimensions of 15mm inner diameter × 21mm outer diameter × 4mm width, is renowned for its compact size, high-speed capability, and low noise characteristics.

Technical Specifications
Bearing Number Inner Diameter (d) Outer Diameter (D) Width (B) Chamfer (r min) Dynamic Load (Cr) Static Load (Cor) Grease Speed Oil Speed Weight (Wt ≈)
61700 ZZ 10 15 3 0.1 800 390 34000 40000 0.00190
61701 ZZ/2RS 12 18 4 0.2 910 530 32000 38000 0.00310
61702 ZZ/2RS 15 21 4 0.2 850 490 28000 32000 0.00360
61703 ZZ/2RS 17 23 4 0.2 960 610 26000 30000 0.00400
6702 ZZ Ball Bearings Specifications
Type Deep Groove Ball
Inner/Outer Ring/Ball Material Chrome Steel
Cage Material Steel
Cage Type Punching
Precision P0, P6
Inner Dimension d(Ø)(mm) 15
Outer Dimension D(Ø)(mm) 21
Width B (or T)(mm) 4
Lubrication Grease
Load Direction Radial
Specifications/Environment Standard
Number of Raceway Ring Rows Single Track
Size Standards Metric Series
Applications

The 6702 2RS deep groove ball bearing with double-sided rubber seals is widely used across various fields due to its specific design and performance characteristics.

  • Home Appliances: Used in washing machines, air conditioner pumps, fans, and soy milk makers for quiet operation and dust protection. Also fits into small devices like smart locks.
  • Industrial Machinery: Suitable for CNC machines, textile equipment, and power tools (drills, grinders) where it handles moderate radial loads at high speeds.
  • Precision Instruments: Ideal for model aircraft, micro motors, and medical diagnostic devices thanks to its small size (15×21×4mm) and high precision.
  • Special Environments: Employed in food processing and wastewater treatment equipment, the sealed design prevents contamination.
