12mm x 18mm x 4mm Deep Groove Ball Bearing Double Sealed 2RS with High-Speed Capability for Thin Section Robot Applications
12mm x 18mm x 4mm Deep Groove Ball Bearing Double Sealed 2RS with High-Speed Capability for Thin Section Robot Applications
Specifications
Bearing Seals :
Double Sealed 2RS -Seal on Two Sides,ZZ or Open available
Interchange :
FAG , NTN ,NSK .....
Clearance :
Standard
Model Numbers: :
6701 2RS,6701-2RS,61701 2RS,61701-2RS Deep Groove Ball Bearings
Brand Name :
CNBTZC or OEM
Model Number :
6701 2RS
Certification :
IATF16949:2016
Place of Origin :
China
MOQ :
50000
Price :
Please contact us,thanks
Payment Terms :
L/C,T/T
Supply Ability :
500000pcs per month
Delivery Time :
2-4 weeks
Packaging Details :
plastic tub/middle box,carton,pallet
Description
6701 2RS Deep Groove Ball Bearings 12mm × 18mm × 4mm Thin Section Robot Bearing
The 61701 2RS / 6701 2RS deep groove ball bearing, with dimensions of 12mm inner diameter × 18mm outer diameter × 4mm width, is renowned for its compact size, high-speed capability, and low noise characteristics.
Technical Specifications & Dimensions
Bearing Number Inner Diameter (d) Outer Diameter (D) Width (B) Chamfer (r min) Dynamic Load (Cr) Static Load (Cor) Grease Speed Oil Speed Weight (Wt ≈)
61700 ZZ 10 15 3 0.1 800 390 34000 40000 0.00190
61701 ZZ 2RS 12 18 4 0.2 910 530 32000 38000 0.00310
61702 ZZ 2RS 15 21 4 0.2 850 490 28000 32000 0.00360
61703 ZZ 2RS 17 23 4 0.2 960 610 26000 30000 0.00400
61704 ZZ 2RS 20 27 4 0.2 1030 720 23000 28000 0.00590
61705 ZZ 2RS 25 32 4 0.2 1090 830 19000 23000 0.00700
61706 ZZ 2RS 30 37 4 0.2 1170 980 16000 19000 0.00830
61707 ZZ 2RS 35 44 5 0.3 1850 1630 14000 17000 0.01500
61708 ZZ 2RS 40 50 6 0.3 2519 2234 12000 15000 0.02300
61709 ZZ 2RS 45 55 6 0.3 2577 2401 9000 13000 0.02500
61710 ZZ 2RS 50 62 6 0.3 2666 2636 7000 10000 0.03400
61711 ZZ 2RS 55 68 7 0.3 2880 3070 5000 8000 0.05500
Product Specifications
Universal Designation
6701 2RS
Type
Deep Groove Ball Bearing
Inner/Outer Ring/Ball Material
Chrome Steel
Cage Material
Steel
Cage Type
Punching
Precision
P0, P6
Inner Dimension d(Ø)(mm)
12
Outer Dimension D(Ø)(mm)
18
Width B (or T)(mm)
4
Lubrication
Grease
Load Direction
Radial
Specifications/Environment
Standard
Number of Raceway Ring Rows
Single Track
Size Standards
Metric Series
Application Areas
Micro Devices and Precision Instruments
  • Micro Motors: Fitness equipment, telecommunications devices, instruments, computer cooling fans
  • Smart Devices: Hair curlers, smart locks, remote control toys, robots
  • Office and Medical Equipment: Hard drive motors, laser engraving machines, dental instruments
Industrial Machinery and Automotive Fields
  • Industrial Equipment: CNC machinery, textile machinery, power tools, gearboxes
  • Automotive Motors: Automotive motors, steering systems
  • Automation Equipment: Transmission parts in automated production lines
Home Appliances and Daily Use Devices
  • Household Appliances: Washing machines, air conditioner motors, vacuum cleaners
  • Small Power Tools: Drills, angle grinders, and other high-speed equipment
Special Environment Applications
  • Food Machinery: Stainless steel versions for corrosion-resistant environments
  • Medical Devices: Surgical instruments, testing equipment requiring high cleanliness
