Specifications
Brand Name :
Coolent
Model Number :
CYA T60-T80
Certification :
ISO/CE
Place of Origin :
China
MOQ :
1
Price :
to be Negotiated
Payment Terms :
T/T
Supply Ability :
1000/Month
Delivery Time :
4W
Packaging Details :
WOODEN
Cooling Capacity :
60-85KW
Mounting :
Floor Standing
Condition :
New
Type :
Chilled water unit/Air cooling unit
After-sales service provided :
Engineers available to service machinery overseas
Operating voltage :
380/400 VAC,230 VAC,220V
Warranty :
1 Year
Name :
Data Center Cooling Unit
Refrigerant :
R22(R407C/R410A)
Application :
Computer Room,Printing factory,Supper market,Restaurant/Offfice/Kindergarten,Industrial,Heat recovery,adjust cold/heat/humidity
Color :
Black Grey White
Power :
3N-380V-50Hz,220v/50hz/60hz
Description

60-85KW Floor Standing High Efficiency And Closed Control Precision Air Handling Units

Product Introduction

Computer room air conditioners refer to a kind of special precision air conditioners (also called constant temperature and humidity air conditioners) that can fully meet the environmental conditions of the computer room. It is a new model that has gradually developed in the past 30 years. When comfortable air conditioners were used in the early computer rooms, there were often problems such as unstable operation of the equipment in the computer room due to improper control of environmental temperature and humidity parameters, interference in data transmission, and occurrence of static electricity.

Benefits

60-85KW Floor Standing High Efficiency Closed Control Precision Air Handling Unit for Data Centers

 60-85KW Floor Standing High Efficiency Closed Control Precision Air Handling Unit for Data Centers

Technical Features

60-85KW Floor Standing High Efficiency Closed Control Precision Air Handling Unit for Data Centers

1. IDC rooms solutions: precise air conditioning, can control temperature, humidity and particle filtration within tight tolerances 24 hours a day and can be remotely monitored.

2. Higher reliable scroll compressor: Famous brand, Copeland, high efficient scroll compressor.
3. High efficient evaporator, energy-saving dehumidify
4. Immersed electrode humidifier: High reliability, well-known brand, Carel.
5. High efficient indoor & outdoor motors: Well-known brand, Ziehl-Abegg.
6. Double wall casing design, improve heat insulation

Heat-insulated casing can prevent the condensate from the unit body.

Galvanized steel sheet of nitrogen treatment and powder spray coating make the casing of indoor unit anti-rust and fire resistance.

7. Accurate microprocessor control technology
8. Air plenum box as optional (only for top delivery models)
9. Easy maintenance
10. Working conditioning: Indoor ambient temperature range 0°C~40°C, outdoor ambient temperature range

Applications

60-85KW Floor Standing High Efficiency Closed Control Precision Air Handling Unit for Data Centers
  • Computer room and data center
  • Switch room and mobile center station in telecommunication
  • High-tech environment and lab
  • Industrial automation control room and precision manufacturing workshop
  • Standard test room and calibration center
  • UPS and battery room
  • Test room in hospital
  • Biochemical culture chamber

Technical Parameters

Model: CYA T26D/U T31D/U T35D/U T41D/U T45D/U T50D/U T55D/U T61D/U T70D/U T76D/U T85D/U T90D/U T100D/U
Power Supply 380V 3Ph-50HZ
Air Discharge Upflow/Downflow
Cooling Capacity :24℃/50%RH
Total Capacity (1) KW 26.9 31.9 35.9 41.9 45.3 50.5 55.4 61.4 70.5 76.2 85.5 90.8 102
Sensible KW 24.8 29.5 33.1 38.8 42.5 47.8 51.6 57.5 65.2 71.2 79.5 84.5 95.7
AEER W/W 3.6 3.6 3.6 3.6 3.6 3.7 3.7 3.6 3.6 3.6 3.6 3.6 3.6
Air Flow m3/h 8000 9500 10000 11500 13000 15500 16000 17500 18500 20500 22500 23500 24200
Compressor Hermetic scroll
Refrigerant R407C
Compressor quantity PC 2 2 2 2 2 2 2 2 2 2 2 2 2
Fan Section Centrifugal fan (Optional EC)
Fan quantity PC 2 2 2 2 2 2 2 2 2 3 3 3 3
Rated current A 4.3 4.3 4.3 4.4 4.4 4.4 5 5.2 5.2 6.5 16.5 16.5 16.5
Rated power W 1600 1600 1800 1800 2000 2000 3000 3300 3900 3900 5400 6300 6300
Total heating capacity KW 6 6 6 9 9 9 9 9 9 12 12 12 12
Material PTC
Humidifier Section Electrode type
Capacity Kg/h 5 5 5 5 13 13 13 13 13 13 13 13 13
Rated Current A 6 6 6 6 15 15 15 15 15 15 15 15 15
Condenser Model 2*58 2*58 2*58 2*58 2*80 2*80 2*100 2*100 2*120 2*150 2*150 2*165 2*180

Certificates

60-85KW Floor Standing High Efficiency Closed Control Precision Air Handling Unit for Data Centers

Factory Details

60-85KW Floor Standing High Efficiency Closed Control Precision Air Handling Unit for Data Centers

Packing & Delivery

60-85KW Floor Standing High Efficiency Closed Control Precision Air Handling Unit for Data Centers

Case

60-85KW Floor Standing High Efficiency Closed Control Precision Air Handling Unit for Data Centers
