Smart Power Distribution Unit With CE And ROHS Certifications
Smart Power Distribution Unit With CE And ROHS Certifications
Smart Power Distribution Unit With CE And ROHS Certifications
Smart Power Distribution Unit With CE And ROHS Certifications
Specifications
Brand Name :
COOLNET
Model Number :
PDU
Certification :
CE& ROHS
Place of Origin :
CHINA
MOQ :
1 unit
Price :
50-500 USD per unit
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
10000 unit per month
Delivery Time :
20 days
Packaging Details :
Standard export packaging
Color :
Black/WHITE
Rated Power :
250V 440V
Phase :
1 or 3 phase
Shell :
Aluminum Shell
Type of plug :
Euro plug Customizable length
Switch Type :
Built-in switch smart pdu
Way :
8 way, 12 way ,16way
PDU type :
RACK PDU
Description

Smart Power Distribution Unit With CE And ROHS Certifications

Production

Intelligent monitoring PDUs are complete and versatile, and can meet the needs of high-end server rooms and data centre software intelligent power distribution and environmental monitoring systems. Intelligent PDUs can monitor both current, voltage, electrical energy, power factor, carbon emissions, fuse status, surge effectiveness and other data. It can also monitor temperature, humidity, flooding, access control, human body sensing, etc. through sensors. Remote control via CP/IP, SNMP and other protocols Power on/off, sequential power on/off, threshold alarm management, authority management, a good helper for power management.

Smart Power Distribution Unit With CE And ROHS Certifications

Product Features

Smart Power Distribution Unit With CE And ROHS Certifications
  • Built-in web server; through a web browser, the real-time power consumption of the distributor can be directly detected
  • When a power event occurs, the system administrator can be notified through Email Traps for processing
  • Can manage the power usage of a large number of distributors at the same time
  • Provide SNMP MIB, the network management system can directly integrate and monitor

Software Function

  • Simultaneously detect the power consumption of multiple intelligent power distributors
  • Group function, administrators can define and classify by themselves, which is convenient for management
  • Provide power consumption icon, which can be viewed by day, month, or self-defined way
 Smart Power Distribution Unit With CE And ROHS Certifications

Smart Power Distribution Unit With CE And ROHS Certifications
Parameter

PDU

Parameters

input

 Input type AC single phase, AC three phase,-48VDC,240VDC,336VDC
Input mode

Transparent open type junction box,power cord, cable,

industrial connector, socket etc.
Input voltage range 100-277VAC/312VAC-418VAC/11VDC-240VDC/-43VDC- -56VDC
AC input frequency 50/60Hz
total load current MAX 63A

Output

 Storage temperature -40 - +70
Relative humidity 5-95% (No condensation)
Atmospheric pressure 70kPa - 106kPa
Working altitude No more than 4000M

Environmental

 Working temperature -10 - +75
Storage temperature -40 - +80
Relative humidity 5-95% (No condensation)
Working altitude No more than 4000M
IP rating IP20
Protection input protection module Circuit breaker, lightning protection, leakage protector, temperature insepction module (optional)
Output protection module Circuit breaker, fuse box, fuse(optional)

Certifications
Smart Power Distribution Unit With CE And ROHS Certifications
Case
Smart Power Distribution Unit With CE And ROHS Certifications

Factory
Smart Power Distribution Unit With CE And ROHS Certifications
