Specifications
Certification :
ISO9001
Place of Origin :
Hebei, China
Coating :
Z81~Z120
Hardness :
Soft
Type :
Steel Coil
Processing Service :
Welding, Punching, Cutting, Bending, Decoiling
Tolerance :
±1%
Width :
10-1500MM
Surface :
Color Coated Steel Coil Ppgi ppgl
Technique :
Prepainted hot Dip Galvanized
Back coating thickness :
5~15micron
MOQ :
1000 pieces
Packaging Details :
Custom packaging
Delivery Time :
Delivery within 15-30 days
Payment Terms :
T/T, PayPal, Xtransfer
Supply Ability :
50000 pieces per day
Description

White Color Code 9016 Prepainted Galvanized Steel Coil 0.4mm Ppgl Ppgi Color Coated Steel Coils


Product Description:

Pre Painted Galvanized Steel Coils are products made from cold-rolled or galvanized steel sheets as the base material, processed through a series of fine techniques. The production process includes surface pretreatment (such as degreasing, cleaning, and chemical conversion treatment), followed by coating with paint through continuous roll coating, and then baking and cooling processes. This coated steel plate is not only lightweight and aesthetically pleasing, but also has excellent corrosion resistance and can be directly processed. It provides innovative raw material choices for multiple fields such as construction, shipbuilding, vehicle manufacturing, home appliance industry, and electrical industry, helping to achieve goals such as efficient construction, energy conservation and emission reduction, and environmental protection.

Features:

1. Strong durability: The corrosion resistance of color coated coils is better than that of ordinary galvanized steel plates, and the service life is longer. For example, the service life of color coated steel strip using hot-dip galvanized steel strip as the substrate is about 1.5 times longer than that of galvanized strip.


2. Good heat resistance: At high temperatures, color coated rolls are less prone to discoloration, maintaining their original color and performance.


3. Excellent thermal reflectivity: Color coated rolls have good thermal reflectivity, which helps reduce the absorption and transfer of heat.


4. Excellent welding performance: Color coated coils are easy to weld, facilitate processing and installation.


5. High cost-effectiveness: Color coated rolls have durable performance and highly competitive prices, and are widely used in various fields.

Technical Parameters:

Standard
ASTM, JIS, EN, DIN, GOST, GB , etc.
Grade
SGCC,CGCC,SGCH,DX51D+Z/DX53D+Z/S220GD-550GD
Thickness
0.13-0.70mm
Length
By coil
Base material
GI/GL/PPGI/PPGL
Zinc Coating
20g/㎡ to 275g/㎡
Coil Weight
3.5-5 ton for normal standard or as customer's request
Painting Thickness
Top side:10-25microns;Back side:3-20microns
Colour
RAL NO./Your sample
Packing
Waterproof paper+plastic film+iron packing+bunding, or as per customer's request

Gold Color Code 9016 Pre Painted Galvanized Steel Coils 0.4mm Ppgl Ppgi

Gold Color Code 9016 Pre Painted Galvanized Steel Coils 0.4mm Ppgl Ppgi

Gold Color Code 9016 Pre Painted Galvanized Steel Coils 0.4mm Ppgl Ppgi

FAQ:

Q:Can you send samples?
A:Of course, we can send samples to all parts of the world, our samples are free, but customers need to bear the courier costs.

Q:What product information do I need to provide?
A:You need to provide the grade, width, thickness, coating and the number of tons you need to purchase.

Q:What are the shipping ports?
A:Under normal circumstances, we ship from Tianjin, Qingdao ports, you can choose other ports according to your
needs.

Q:About product prices?
A:Prices vary from period to period due to cyclical changes in the price of raw materials.

Q:What are the certifications for your products?
A:We have ISO 9001, SGSand other certifications.

Q:How long does your delivery time take?
A:In general, our delivery time is within 30-45 days, and may be delayed if the demand is extremely large or special circumstances
occur.

Q:Can I go to your factory to visit?
A:Of course, we welcome customers from all over the world to visit our factory. However, some of the plants are not open to the
public.

Q:Does the product have quality inspection before loading?
A:Of course, all our products are strictly tested for quality before packaging, and unqualified products will be destroyed.

Q:How to pack the products?
A:The inner layer has a waterproof paper outer layer with iron packaging and is fixed with a fumigation wooden pallet. It can
effectively protect products from corrosion during ocean transportation.

Q:What is your working time?
A:In general, our online service time is Beijing time: 8:00-22:00, after 22:00, we will reply to your inquiry during the next working day.
