Bulk Hard Polypropylene Plastic Sheets Boards Electrical Insulated Custom
Bulk Hard Polypropylene Plastic Sheets Boards Electrical Insulated Custom
Bulk Hard Polypropylene Plastic Sheets Boards Electrical Insulated Custom
Bulk Hard Polypropylene Plastic Sheets Boards Electrical Insulated Custom
Specifications
Brand Name :
Xinkunda
Model Number :
Customizable according to requirements
Certification :
ISO9001，ISO14001，ISO45001
Place of Origin :
Chengdu, Sichuan, China
MOQ :
1ton
Price :
1535 USD/metric ton (current price)
Payment Terms :
,T/T
Supply Ability :
2000 tons/month
Delivery Time :
2-7 days
Packaging Details :
Stacked strapped packaging and boxed or pallet packaging with outer waterproof canvas covering
Density :
0.9 g/cm3
Color :
White/gray/beign/cyan/blue
Thickness :
3-30mm
Size :
Customized
Temperature Resistance :
Up to 120°C
Weather Resistance :
Good
Electrical Insulation :
High
Uv Resistance :
Good
Surface Finish :
Smooth
Material :
PP(Polypropylene)
Description
PP Boards Available In Various Fields With Outstanding Electrical Insulation
Product Specifications
Attribute Value
Density 0.9 g/cm3
Color White/gray/beige/cyan/blue
Thickness 3-30mm
Size Customized
Temperature Resistance Up to 120°C
Weather Resistance Good
Electrical Insulation Excellent
UV Resistance Good
Surface Finish Smooth
Material Polypropylene
Insulation Performance

PP sheets have significant advantages in terms of insulation. They are excellent electrical insulating materials with high volume resistivity, which can effectively prevent the passage of electric current. Moreover, their insulation performance is less affected by temperature, remaining stable within the range of room temperature to 80°C, and is not prone to insulation failure due to changes in ambient temperature. At the same time, they also have good arc resistance, being not easily damaged by arc burns to the insulation layer. In addition, they possess excellent chemical stability; when in contact with acids, alkalis, moisture and other environments, their insulation performance does not decrease significantly, and they can maintain reliable insulation effects for a long time.​

Relative Applications

Based on these insulation properties, PP sheets are applied in multiple fields. In the manufacturing of electrical equipment, they are often used as lining plates and insulation partitions for distribution boxes and junction boxes to prevent short circuits or electric leakage. In the electronics industry, they can serve as separation pads for electronic components to avoid interference caused by electric leakage between components. In the field of communication equipment, they are used to make insulation layers of cable protection tubes, ensuring that signal transmission is not affected by external currents. Furthermore, in some humid or corrosive electrical environments, such as insulation panels of electrical operation platforms in chemical workshops, PP sheets can also play an important role relying on their stable insulation performance.

Insulation Performance Between PP And Other Materials
Material Insulation Properties Main Applications
PP Board (Polypropylene Board) Excellent electrical insulation, chemical resistance, low dielectric constant Chemical containers, lab equipment, electronic component insulation
PVC Board (Polyvinyl Chloride Board) Good electrical insulation, flame retardant Construction decoration, pipelines, advertising panels
PE Board (Polyethylene Board) Good electrical insulation, low-temperature resistance, poor high-temperature resistance Packaging materials, waterproof layers, food containers
ABS Board (Acrylonitrile Butadiene Styrene Board) Moderate insulation, high strength, easy to process Auto parts, toys, electronic product casings
Epoxy Resin Board Excellent insulation, high-temperature resistance, strong mechanical properties Circuit boards, insulating gaskets, aerospace materials
Plywood Moderate insulation, prone to moisture (requires treatment) Construction formwork, furniture, interior decoration
Aluminum Plate Conductive (requires insulation treatment) Building facades, radiators, decorative panels
