LED CT PT Testing , 5A Current Transformer Burden Test
LED CT PT Testing , 5A Current Transformer Burden Test
Specifications
Brand Name :
HNMC
Model Number :
FL2
Place of Origin :
China
MOQ :
1
Price :
Negotiable
Supply Ability :
50 sets per month
Delivery Time :
30-45 days
Packaging Details :
Wooden Package
Rated Current :
5A, 1A
Working current range :
1-120%
Working frequency :
50 or 60HZ
Application :
lab, CT PT manufacturer
Display :
LED
Accuracy :
3%
Description

Intelligent Type Current Transformer Burden Box CT Burden FL2 series

Working as secondary load during current transformer testing

Full automatic

Can provide communication protocol

Technical Parameter

Rated Current 5A, 1A
Working Current Range 1-120% or up to 200%
Rated Impedance (Ω)

COSφ= 0.8 0.1；0.15；0.2；0.3；0.4；；0.6；1.0；1.2; 1.6; 2.4; 3.2

COSφ= 1.0 0.1；0.15；0.2；0.3；0.4
Working Frequency 50/60HZ
Basic Error
Active (±3+0.003*100/R)%·R(Ω)
Reactive (±3+0.003*100/X)%·X(Ω)
Test voltage: 2KV One minute

Customization is available.

Note:

1. Open circuit is not allowed during testing

2. In order to avoid the cause of impedance change, ont knock coil installation place in burden box.

3. Working condition:+10℃—+40℃ / RH 30-85%,indoor

Technical service

Much experienced technical team will provide strong technical support for your market development. We can provide support on customization, maintenance, device design, construction scheme, design optimization, and product development.

Quality control

We have professional quality control team. Our quality control covers materials, production procedure, finished product inspection, final inspection before loading, inspection report.
