100V Power Test Equipment , 20mA Surge Arrester Tester
100V Power Test Equipment , 20mA Surge Arrester Tester
Specifications
Brand Name :
Metrum
Model Number :
MCZA 6820
Place of Origin :
China
MOQ :
1 pc
Supply Ability :
200 Pcs
Packaging Details :
Carton package
Price :
Negotiable
Application :
worksite
Test current :
0-20mA
Power supply :
220V+/-10% and Rechargeable Battery
Weight :
Approx 5KGs
Description

ZnO Surge Arrester On-line Tester MCZA 6820

Function & Character

  • 800X480 lattice 65K true color LCD display, data is clear and legible.
  • High accuracy sampling, processing circuit, Advance Fourier harmonic analysis technology, data is reliable.
  • Directly collect signal of voltage and current.
  • Test harmonic content- 3,5,7order harmonic wave in single or three phase or at the same time.
  • Have resistive current basic wave peak output function
  • With inbuilt memory, can save 50 groups test datum and test result.
  • With USB Port, could save arbitrary data.
  • Voltage and current test cable have prevent wrong connection function,
  • Have wireless transmitting module,wireless acquisition and match host to measure wireless.
  • Inbuilt high accuracy real-time o’clock, calibrate date and time in any time.
  • With high speed thermal printer, can print test result at site
  • With rechargeable battery as power supply, would work more than 6 hours continuously ,also have low battery signal and current range indicator on the display

Technical Index

1. voltage and current parameter :

Test item Test range Test accuracy
Full current 0-20mA ±(readingX5%＋5µA)
Resistive current 0-20mA ±(readingX5%＋5µA)
Capacitive current 0-20mA ±(readingX5%＋5µA)
Current harmonic 0-20mA ±(readingX10%＋10µA)
Reference voltage Max.100V RMS ±(readingX5%＋0.5V)
Voltage harmonic Max.100V RMS

±(readingX10%

2. transmitting distance: apparent 500m

3. Power supply: AC220V±10%, 50HZ / Rechargeable Battery (can continuously work for 6 hour or more after 3-hour charging

4. Dimension: 320*260*135mm

5. work temperature: -10℃-40℃

6. Relative humidity: ≤85% non condensing

7. Storage temperature: -20℃-50℃

8. Weight: approx 5.0KG

Packing list

1 Host machine 1 No 6 Charger 1 No
2 Wireless module 1 No 7 Print paper 1 Roll
3 Air wire 2 Nos 8 Use manual 1 copy
4. Test cable 1 set 9 Routine report 1 copy
5 Fuse (0.1A) 4 pcs
