PWM Fan Finished Product Testing System 100RPM-60000RPM
PWM Fan Finished Product Testing System 100RPM-60000RPM
Specifications
Brand Name :
Topfer
Model Number :
TP-3120
Place of Origin :
china
MOQ :
one set
Price :
to be discussed
Payment Terms :
T/T
Supply Ability :
10 sets /30 days
Delivery Time :
2 to 3 weeks
Packaging Details :
wooden crate
Condenser Type :
Shell and Tube
Weight :
Depends on configuration
Protection System :
High and Low Pressure Protection, Overload Protection, Anti-freezing Protection
Temperature Range :
-10℃ to 30℃
Compressor Type :
Scroll
Evaporator Type :
Shell and Tube
Control System :
Microcomputer
Refrigerant :
R410a
Power Supply :
380V/3Ph/50Hz
Description

FAN FINISHED PRODUCT TESTING SYSTEM

Technical parameters

Signal detection, test content :

1.F00/PG square wave,

2. R00/RD locking jumps from low to high,

3. FRO square wave locking is high,

4. BRO locking jumps from high to low,

5. Two wires,

6. ROI first lock jumps from low to high,

7. BROI first lock jumps from high to low.

Voltage, current:

Current, speed, high and low level of OP/FG signal, waveform width-to-height ratio, high-to-low ratio, surge, waveform comparison, low voltage start, ten-stage PWM parameter test, automatic archiving of test data, upload to network or database.

Duty cycle:

0%-100% continuously adjustable via program control

PWM amplitude:

Arbitrary adjustment from 1.25V to 12V

Detection range:

100-60000 RPM (four-pole), 100-30000 RPM (eight-pole)

Error:

10RPM士0.1%

Startup mode:

Button, No button, Barcode, Barcode + Button.

Test type:

PWM model, Two wires, FG signal, Vibration test

Configuration function:

One PC/monitor, one function test box; data transmission lines and peripheral wiring. Power supply. Configured according to current and voltage requirements, can be configured with ① optical fiber to capture fan speed stop time ② RSBP.
