Affordable 600VA Offline UPS with Surge Protection for Home Office
Key Features
- Compact, sleek, and elegant machine design
- Ultra-wide AC input range
- Advanced microprocessor ensures reliable operation
- Automatic voltage regulation for stable output
- AC restart function
- Overload protection
- Shutdown charging function
- Cold start capability
- Generator compatible
K Series UPS Selection Guide (Technical Specifications)
| Capacity |
600VA / 360W |
1000VA / 480W |
1200VA / 720W |
2000VA / 1200W |
3000VA / 1600W |
| Input Specifications |
| Voltage |
220VAC |
| Voltage Range |
145-280 VAC |
| Frequency |
50/60 Hz |
| Output Specifications |
| Voltage Range (Battery Mode) |
±10% |
| Frequency Range (Battery Mode) |
50/60HZ ±1HZ (Auto-adaptive) |
| Transfer Time |
Typically 2-6 ms, maximum 10ms |
| Waveform (Battery) |
Square Wave |
Sine Wave |
| Battery Specifications |
| Battery Model & Quantity |
12V 7Ah * 1 |
12V 9Ah * 1 |
12V 7Ah * 2 |
12V 9Ah * 2 |
12V 7Ah * 4 |
| Charging Time |
6 hours to 90% |
4 hours to 90% |
Indicator Lights
| AC Mode |
Green light on - displays AC power and load capacity |
| Battery Mode |
Red light flashing - displays battery capacity |
Audible Alarms
| Battery Mode |
Beeps every 6 seconds |
| Low Battery |
Beeps every 1 second |
| Overload |
Beeps every 0.5 seconds (2 beeps per second) |
| Error |
Continuous beeping |
Protection Features
- Comprehensive protection: Overload, deep discharge, and overcharge protection
Physical Specifications
| Model |
K600 |
K1000 |
K1200 |
K2000 |
K3000 |
| Unit Dimensions D*W*H (mm) |
335*87*143 |
312*122*195 |
405*144*213 |
| Net Weight (kg) |
4.4 |
6.9 |
8.4 |
12.3 |
17.6 |
| Package Dimensions D*W*H (mm) |
392*142*205 |
403*225*295 |
483*227*318 |
| Gross Weight (kg) |
4.6 |
7.4 |
8.8 |
13.0 |
18.5 |
Operating Environment
| Temperature & Humidity |
Relative humidity 0-90% and temperature 0-40°C (non-condensing conditions) |
| Noise Level |
Less than 40dB @ 1 meter distance |
