SETsafe | SETfuse H6
SETsafe | SETfuse H6
Specifications
Operating Temperature :
140℃
Packaging Details :
Through Hole,D2.5xL9mm
Rated Functioning Temperature :
145℃
Brand Name :
SETsafe | SETfuse
Maximum Temperature Limit :
200℃
Holding Temperature :
121℃
Stock :
2100
Voltage Rating :
250V
Model Number :
H6
Delivery Time :
17-19 working days
Description :
145℃ 250V 2A 121℃ 140℃ Through Hole,D2.5xL9mm Thermal Cutoffs (Thermal Fuses) RoHS
Current Rating :
2A
MOQ :
453
Description

Product Overview

The H-Series Thermal-Link (ATCO) is a non-resettable thermal cutoff device designed for circuit protection. It consists of a low-melting-point fusible alloy, flux, housing, sealing resin, and leads. When the device reaches its rated fusing temperature due to abnormal heating, the alloy melts and retracts, effectively opening the circuit. Features include precise operating temperatures, one-time operation, and environmental compliance (RoHS/REACH).

Applications: Lighting, Switching Power Supplies, Home Appliances, Transformers, Motors, Electric Blankets.

Brand: SETsafe | SETfuse
Series: H Series
Rated Current: 2 A
Operating Temp Range: 76 C to 221 C
Certifications: UL, cUL, TUV, PSE, KC, CCC
ModelFusing Temp (C)Holding Temp Th (C)Limit Temp Tm (C)Rated Current Ir (A)Rated Voltage Ur (V)
H31218 21882502250 AC / 125 AC / 60 DC
H32199 31692502250 AC / 125 AC / 60 DC
H17182 21622502250 AC / 60 DC
H16154 21352002250 AC / 60 DC
H7145 21262002250 AC / 50 DC
H6140 21212002250 AC / 50 DC
H13135 21152002250 AC / 50 DC
H9131 21122002250 AC / 50 DC
H5130 21112002250 AC / 50 DC
H8130 21112002250 AC / 50 DC
H4125 21062002250 AC / 50 DC
H3121 21002002250 AC / 60 DC
H2111 2912002250 AC / 50 DC
H198 3792002250 AC / 125 AC / 50 DC
H2193 2702002250 AC / 125 AC / 50 DC
H1881 2612002250 AC / 125 AC / 50 DC
H073 2532002250 AC / 125 AC / 50 DC
