TE Connectivity 1971858-3
TE Connectivity 1971858-3
Specifications
Brand Name :
1971858-3
Model Number :
1971858-3
Description :
Barrel, Bullet Connectors RoHS
Delivery Time :
4-6 working days
MOQ :
1
Packaging Details :
-
Stock :
44
Description

Product Overview

The SOLARLOK PV4 CONNECTOR is a socket contact designed for solar cable applications. It is used for crimping solar cables of sizes 4mm/12AWG and 6mm/10AWG. For optimal performance and safety, it is recommended to use only TE Connectivity's crimping tools, specifically part number 6-1579014-8 for the specified wire sizes. Avoid direct contact with the contacts by hand without protection.

Brand

TE Connectivity

Product Type

SOCKET CONTACT

Series

SOLARLOK PV4 CONNECTOR

Material

COPPER ALLOY, TIN PLATED

Application Specification

Used for solar cable: 4mm/12AWG, 6mm/10AWG.

Usage Recommendation

Do not touch the contact directly by hand without any protection. Use only crimping tool of TE Connectivity to crimp contact.
PART NUMBER PACKING UNIT UNIT FOR ORDER DIMENSIONS (mm) TOLERANCES (mm)
1971858-6 LOOSE PIECE 1 5.0 x 4.6 x 5.9 x 33.4 REF. 0.5
1971858-5 LOOSE PIECE 10 5.0 x 4.6 x 5.9 x 33.4 REF. 0.5
1971858-4 STRIP 100 5.0 x 4.6 x 5.9 x 33.4 REF. 0.5
1971858-3 STRIP 100 5.0 x 4.6 x 5.9 x 33.4 REF. 0.5
1971858-2 STRIP 1000 5.0 x 4.6 x 5.9 x 33.4 REF. 0.5
DRAWING NO CUSTOMER DRAWING PRODUCT SPEC APPLICATION SPEC WEIGHT FINISH
108-106078 1971858 114-106078 4mm/12AWG, 6mm/10AWG 0.3 TIN
