Low Noise Cummins Engine 625kva 500kw Diesel Generator Silent Diesel Gensets
Low Noise Cummins Engine 625kva 500kw Diesel Generator Silent Diesel Gensets
Low Noise Cummins Engine 625kva 500kw Diesel Generator Silent Diesel Gensets
Low Noise Cummins Engine 625kva 500kw Diesel Generator Silent Diesel Gensets
Low Noise Cummins Engine 625kva 500kw Diesel Generator Silent Diesel Gensets
Low Noise Cummins Engine 625kva 500kw Diesel Generator Silent Diesel Gensets
Specifications
Brand Name :
GPRO
Model Number :
GP668CCS
Certification :
ISO9001/ ISO14001/ CE
Place of Origin :
China
MOQ :
1
Price :
45770-50128
Delivery Time :
one month
Packaging Details :
Poly wooden case / Poly bag
Genertor prime power :
500KW / 625KVA
Generator standby power :
550KW / 688KVA
500KW generator engine :
With Cummin s engine KTAA19-G6A
500kw generator alternator :
STAMFORD / MECC
500KW silent generator noise :
80dB at 7 meters
500KW Generator controller :
Smartgen / DeepSea
500KW generator certificate :
ISO9001/ ISO14001/ CE
Generator 500kw fuel tank :
8 hours when 100% loading
ATS :
Socomec / Aiskai
Description

Low Noise Cummins Engine 625kva 500kw Diesel Generator Silent Diesel Gensets

Technical specification
Genset Model GP688CCS
Prime Power 500KW/625KVA
Standby Power 550KW/688KVA
Phase Number 3
Power Factor 0.8
Rated Voltage 230/400V
Frequency 50 HZ
Rated Current 902A
Genset Structure SILENT
Dimension 5000×1800×2450mm
Net Weight 5500KG
Noise level 83dB at 7 meters
Fuel Tank Capacity 800L
Engine Model KTAA19-G6A
Engine Features 6-cylinder,4 stroke,water cooled ,Turbo
Bore * Stroke 159mm × 159mm
Displacement 18.9L
MAX Power(kw) 575KW/1500
Fuel Consumption L/H 129.5L/H
Compression Ratio 13:01
Governor type ELECTIC
Alternator Model STAMFORD /HCI544FS
Excitation Mode brushless self-excited
Insulation Class H
Protection Class IP23
Construction Type SAE Disc-coupling
Controler panel
Smartgen 6120 intelligent and network techniques is used for automatic control system of diesel generator. It can carry out functions including automatic start/stop, data measure and alarming.automatic switching control functions (AMF), especially suitable for the automation system composed by Mains and Generator

Low Noise Cummins Engine 625kva 500kw Diesel Generator Silent Diesel Gensets
