48 Volt Small Brushless Dc Electric Motor High Torque 175mm Drop Out
48 Volt Small Brushless Dc Electric Motor High Torque 175mm Drop Out
48 Volt Small Brushless Dc Electric Motor High Torque 175mm Drop Out
48 Volt Small Brushless Dc Electric Motor High Torque 175mm Drop Out
Specifications
Brand Name :
OEM
Model Number :
NC-F
Certification :
CE
Place of Origin :
CHINA
MOQ :
10
Price :
Negotiable
Payment Terms :
T/T, Paypal , Alibaba Trade assurance
Supply Ability :
5,000pcs per month
Delivery Time :
15 working days after received your payment
Packaging Details :
carton box with foam, package size : two motors in one box, the size is 43*28*28
motor power :
500watts
voltage :
36v
pack weight :
4kgs
drop out :
175mm
color :
sliver white or black
speed :
25-35
Description

NC-F High efficiency 25-35kph speed electric motor 48v rear hub motor 500w electric bicycle brushless geared dc hub motor

The 36v 500w geared motor drawing photos :

48 Volt Small Brushless Dc Electric Motor High Torque 175mm Drop Out

The NC-F 36v 500w electirc bike hub geared motor spec. details :

The big torque 50N.M for geared motor 500watts .

Model NCF(Fat bike)
Motor power 350/500W
Weight 3.5/4kg
Type rear motor
Voltage 36v/48v
Magnet Height 27/30mm
Design Geared
Dropout Width 175
Speed 25-35kph
Spoke Specs 12G/13G
Max torque 35/50N.M
Max Efficiency >80%
Cassette Style n/a
Brake V/Disc brake
Surface color dark black/ sliver white

48 Volt Small Brushless Dc Electric Motor High Torque 175mm Drop Out

Description for 36v 500w geared hub motor:

  • cheaper price
  • brushless gearless design
  • Electricity saving, 88%
  • High torque, 50 N.M
  • Long service life
  • suitable for 20"-29" wheels
  • Warranty : 2 years
  • OEM

l PRODUCT PACKING

  • Material : carton with foam
  • Packing size:About 43*28*28 ,one carton include 2psc
    Packing weight:about 13kg"

48 Volt Small Brushless Dc Electric Motor High Torque 175mm Drop Out
