33kv 3C*95mm2 Power Cable Copper Conductor Low Voltage XLPE PVC PE Insulation Steel Wire Armour Industrial Underground
33kv 3C*95mm2 Power Cable Copper Conductor Low Voltage XLPE PVC PE Insulation Steel Wire Armour Industrial Underground
33kv 3C*95mm2 Power Cable Copper Conductor Low Voltage XLPE PVC PE Insulation Steel Wire Armour Industrial Underground
33kv 3C*95mm2 Power Cable Copper Conductor Low Voltage XLPE PVC PE Insulation Steel Wire Armour Industrial Underground
33kv 3C*95mm2 Power Cable Copper Conductor Low Voltage XLPE PVC PE Insulation Steel Wire Armour Industrial Underground
33kv 3C*95mm2 Power Cable Copper Conductor Low Voltage XLPE PVC PE Insulation Steel Wire Armour Industrial Underground
33kv 3C*95mm2 Power Cable Copper Conductor Low Voltage XLPE PVC PE Insulation Steel Wire Armour Industrial Underground
33kv 3C*95mm2 Power Cable Copper Conductor Low Voltage XLPE PVC PE Insulation Steel Wire Armour Industrial Underground
33kv 3C*95mm2 Power Cable Copper Conductor Low Voltage XLPE PVC PE Insulation Steel Wire Armour Industrial Underground
33kv 3C*95mm2 Power Cable Copper Conductor Low Voltage XLPE PVC PE Insulation Steel Wire Armour Industrial Underground
33kv 3C*95mm2 Power Cable Copper Conductor Low Voltage XLPE PVC PE Insulation Steel Wire Armour Industrial Underground
33kv 3C*95mm2 Power Cable Copper Conductor Low Voltage XLPE PVC PE Insulation Steel Wire Armour Industrial Underground
Specifications
Place of Origin :
Henan, China
Brand Name :
Aobest
Model Number :
Cu/XLPE/PVC High Voltage Cable
Insulation Material :
xlpe
Type :
LOW VOLTAGE
Application :
Underground
Conductor Material :
Copper
Jacket :
PVC
Product name :
Copper Core PVC Insulated Electrical Power Cable
Certificate :
ISO9001/ISO14001 /OHSAS18001/CCC
Standard :
IEC60502
Conductor :
Copper Core
Insulation :
XLPE PE PVC
Sheath :
Flame Retardant PVC
Package :
Wooden Drum
MOQ :
500 meters
Price :
$22.00/meters
Description
Specifications for High Voltage Power Cable:
XLPE/PVC High Voltage Power Cable
1.Aluminium or Copper Conductor XLPE Insulated Armored Cable
2.0.6kV~1kV~35kV

XLPE/PVC High Voltage Power Cable

Application:
Power cables for power networks, underground, outdoors and in cable ducting.
Standards:
ASTM, BS6622, IEC etc.
Conductor:
Class 2 stranded plain copper conductor to BS EN 60228:2005 (previously BS6360)
Conductor screen:
Semi-conducting material
Insulation:
XLPE (Cross-Linked Polyethylene) Type GP8 to BS7655
Insulation Screen:
Semi-conducting material
Metallic Screen:
Individual and overall copper tape screen to BS6622
Filler:
PETP (Polyethylene Terephthalate) fibres
Separator:
Binding tape
Bedding:
PVC (Polyvinyl Chloride) Type TM1 to BS7655
Armouring:
Single Core: Aluminium Wire Armoured (AWA)
Multi-core: Steel Wire Armoured (SWA)
Sheath:
PVC (Polyvinyl Chloride) Type TM1 to BS7655
Colour:
Red or Black or as clients' request
Voltage Rating:
19000/33000V
Temperature Rating:
0°C to +90°C
Minimum Bending Radius:
Single Core: 15 x overall diameter
Three Core: 12 x overall diameter
(Single Core 12 x overall diameter and 3 core 10 x overall diameter where bands are positioned adjacent to joint or terminations provided that the bending is carefully controlled by the use of a former)

We can provide more info than above data, if needed.The above are just some examples.

Customer's specifications are available upon request.
